1000W High Power Density AC DC enclosed switching power supply LMF1000-20B Series

MORNSUN 1000W AC/DC enclosed power supply LMF1000-20B.jpg


At the beginning of April, MORNSUN introduced the new 1000W AC/DC enclosed power supply LMF1000-20B series, and now the power range of MORNSUN AC/DC enclosed power supply is 15-1000W which can meet the different demands of various applications.


The LMF1000-20B has the advantages of small size (190*127*40.5mm), high power density, variable speed fan control, can be connected in parallel to boost power, etc. They meet IEC/UL/EN62368, GB4943, IEC/ES/EN60601 standards, which makes them the safe, reliable and cost-effective power converters widely used in industrial control systems, automation machinery, measurement and control instruments, medical (medical certification), etc.


Product advantages

1) Compact size, high power density

Small size of 190*127*40.5mm, high power density of 17.22W/inch3


2) Operating temperature range: -40℃ to +70℃


3) High reliability, long lifespan

a. High isolated voltage of 4000 VAC, meet IEC/UL/EN62368, GB4943, IEC/ES/EN60601 standards

b. Vibration resist, 10 to 500 Hz, 5g 10 min/cycle, 60 min each for X, Y and Z

c. 5-year warranty

d. Multiple protections of output short-circuit, over-voltage, over-current and over-temperature

e. Can be connected in parallel to boost power, meet customer’s redundancy design


4) Energy saving

a. Efficiency up to 94%

b. High power factor(115Vac ,full load, PF:0.99 typ)

c. Variable speed fan control


5) Digitization

a. Remote ON/OFF

b. DC OK function

c. I2C communication

d. Remote Sense compensation function


6)Meet EMI CISPR32/EN55032 CLASS B without peripheral components


Application

They can be widely used in industrial control systems, automation machinery, laser instruments, aging equipment, measurement and control equipment, medical, etc.

MORNSUN 1000W AC/DC enclosed power supply LMF1000-20B.jpg


Features

● Input voltage range: 90 - 264VAC/120 - 370VDC

● Operating temperature range: -40℃ to +70℃

● Variable speed fan control

● Remote ON/OFF, digital communication;

● Support 3+1 parallel redundancy, current-sharing accuracy: <5%

● Meet 5000m altitude application

● High power density

● Meet EMI CISPR32/EN55032 CLASS B without peripheral components
● Meet IEC/UL/EN62368, GB4943, IEC/ES/EN60601 standards

Please refer to the technical manual for specific product parameters:

Series Power(W) Vin(VAC) Vin(VDC) Nominal Vout and Io(V/A) No. of Outputs Efficiency(%) Isolation(VAC) Footprint & 3D Certification Datasheet Sample Buy
LMF1000-20B12 960 90-264 120-390 12V/80A 1 92 4000
-
LMF1000-20B15 960 90-264 120-370 15V/64A 1 92 4000
-
LMF1000-20B24 1008 90-264 120-390 24V/42A 1 94 4000
-
LMF1000-20B27 1007 90-264 120-370 27V/37.3A 1 94 4000
-
LMF1000-20B36 1008 90-264 120-370 36V/28A 1 94 4000
-
LMF1000-20B48 1008 90-264 120-390 48V/21A 1 94 4000
-
LMF1000-20B54 1009 90-264 120-370 54V/18.7A 1 94 4000
-
