30W High-efficiency Medical Open-frame AC/DC Power Supply LO30-20BxxMU Series

30W High-efficiency Medical Open-frame AC/DC Power Supply LO30-20BxxMU Series.jpg

To meet the demand for medical power supply for low power applications, MORNSUN launches the high-efficiency miniaturized LO30-20BxxMU series, which is the extension of 30W products after 45W/65W/120W series of medical power supplies.


The LO30-20BxxMU series has the advantages of small size (3"*2"), leakage current as low as 75μA, high efficiency, and low power consumption, etc. It meets the reinforced insulation 2xMOPP and medical certification EN60601-1. And this medical ac dc power supply is suitable for all kinds of BF type (be accessible to patients) medical system equipment, clinical medical equipment, ventilator equipment, and personal care device, etc.


Advantages of LO30-20BxxMU Series AC/DC Power Supply

(1) Compact size: 3”*2” (76.20 x 50.80 x 24.00 mm)

(2) Simplified design: Compact layout design

(3) Medical certification

a. Extremely low leakage current<75μA

b. Meets 2 x MOPP safety certification

c. Designed to meet IEC/EN60601-1, UL/EN/IEC62368-1, IEC/EN60335-1, EN61558-1 standards

(4) High-reliability

a. Operating temperature range:-30℃ to +85℃

b. Efficiency up to 90%

c. Meet EN61558-1 and OVC III


Applications of Mornsun Open-frame AC/DC Power Supply

With a high-reliable design for the medical industry, the LO30-20BxxMU series also can be used in industrial control, LED, street light control, electric power, security, communication, smart home, etc.

MORNSUN LO30-20BxxMU series suitable for all kinds of BF type medical system equipment, especially Ventilator.jpg


Features of Mornsun 30W High-efficiency AC/DC Power Supply

● Universal input voltage range: 80-264VAC or 100-370VDC

● Meets 2 x MOPP safety certification

● Suitable for BF application

● Operating temperature range: -30℃ to +85℃

● High I/O isolation voltage up to 4000VAC

● Meets 5000m altitude requirements

● Extremely low leakage current<75μA

● Stand-by power consumption<0.25W

● Output short circuit, over-current, and over-voltage protection

● Efficiency up to 90%

● Meet EN61558-1 and OVC III



* For detailed information please refer to the related datasheet, product news is for reference only.
Please refer to the technical manual for specific product parameters:

Series Power(W) Vin(VAC) Vin(VDC) Vout(VDC) Iout No. of Outputs Isolation Package Dimension(mm) Footprint & 3D Markings Datasheet Sample Buy
LO30-20B03MU 19.8 80-264 100-370 3.3 6A 1 4000VAC Open frame 76.20*50.80*24.00
LO30-20B05MU 30 80-264 100-370 5 6A 1 4000VAC Open frame 76.20*50.80*24.00
LO30-20B12MU 30 80-264 100-370 12 2.5A 1 4000VAC Open frame 76.20*50.80*24.00
LO30-20B15MU 30 80-264 100-370 15 2A 1 4000VAC Open frame 76.20*50.80*24.00
LO30-20B19MU 30 80-264 100-370 19 1.58A 1 4000VAC Open frame 76.20*50.80*24.00
LO30-20B24MU 30 80-264 100-370 24 1.25A 1 4000VAC Open frame 76.20*50.80*24.00
LO30-20B36MU 30 80-264 100-370 36 0.833A 1 4000VAC Open frame 76.20*50.80*24.00
LO30-20B48MU 30 80-264 100-370 48 0.625A 1 4000VAC Open frame 76.20*50.80*24.00
