5W High power density AC/DC converter for flexible design-encapsulated LS05-23BxxDR3 series

5W High power density AC/DC converter for flexible design-encapsulated LS05-23BxxDR3 series.jpg

In product design, the open-frame power converter is requested to keep a specific contact distance with the periphery. But for more and more compact layout requirements, encapsulated power modules can greatly reduce the distance from the peripheral devices to meet the Pollution degree 3 (meet IEC62368-1). MORNSUN newly LS05-23BxxDR3 series, upgraded from the typical LS-R3 series, is in an encapsulated package, satisfying space-limited applications.


These LS05-23BxxDR3 have the advantages of the ultra-compact size of 27.60 x 18.50 x 7.80mm, high reliability, high insulation, etc. They are suitable for industrial control, power instrumentation, smart home, and applications with space-limited or harsh conditions.


Advantages

1) Ultra-wide input voltage range

85 - 305VAC and 70 - 430VDC, accepts AC or DC input (dual-use of the same terminal)


2) Ultra-thin thickness and compact size (27.60 x 18.50 x 7.80mm)

High power density with a thickness of 7.80mm


3) High-reliable encapsulated package

a. Pollution degree 3 (meet IEC62368-1), resistant to corrosion and aging

b. Decrease the contact distance with the periphery but safer

c. High I/O isolation test voltage up to 4000VAC

d. High insulation

e. Encapsulated package enhances the actual life of the power supply


4) Wide operating temperature

Operating temperature range: -40℃ to +85℃


5) Comply with Safety Standard

Comply with EN62368, IEC/EN61558, IEC/EN60335 standards



Applications

These products are suitable for industrial control, power instrumentation, smart home, LED, street light control, electricity, security, communication, etc.


MORNSUN These products are suitable for industrial control, power instrumentation, smart home, LED, street light control, electricity, security, communication, etc..jpg


Features

● Ultra-wide input voltage range:85 - 305VAC and 70 - 430VDC

● Accepts AC or DC input (dual-use of the same terminal)

● Operating temperature range: -40℃ to +85℃

● Flexible design for versatile applications

● Compact size, high power density, environment friendly

● Controllable lifespan and cost

● No-load power consumption as low as 0.1W

● High I/O isolation test voltage up to 4000VAC

● The plastic case meets UL94V-0 flammability

● Output short circuit and over-current protection

● Comply with IEC/EN61558、IEC/EN60335 standards

● Comply with EN62368 standards


* For detailed information please refer to the related datasheet, product news is for reference only.
Please refer to the technical manual for specific product parameters:

Series Power(W) Vin(VAC) Vin(VDC) Vout(VDC) Iout No. of Outputs Isolation Package Dimension(mm) Footprint & 3D Markings Datasheet Sample Buy
LS05-23B03DR3 3.3 85-305 70-430 3.3 1000mA 1 4000VAC SIP 27.60*18.50*7.80
LS05-23B05DR3 5 85-305 70-430 5 1000mA 1 4000VAC SIP 27.60*18.50*7.80
LS05-23B09DR3 5 85-305 70-430 9 560mA 1 4000VAC SIP 27.60*18.50*7.80
LS05-23B12DR3 5 85-305 70-430 12 420mA 1 4000VAC SIP 27.60*18.50*7.80
LS05-23B15DR3 5 85-305 70-430 15 340mA 1 4000VAC SIP 27.60*18.50*7.80
LS05-23B24DR3 5 85-305 70-430 24 210mA 1 4000VAC SIP 27.60*18.50*7.80
