DIN-Rail High Isolated Compact Size Power Supply Series LI120-20BxxR2

MORNSUN launched a high isolated compact size DIN-Rail power supply LI120-20BxxPR2 series, which is designed to supply low-voltage bus power supply for control cabinet systems with internal rails for industrial control, new energy, petrochemical metallurgy, railway, DC charging piles, etc. Till now, the LIxx-20BxxPR2 series covers output power 30W, 60W, 100W, 120W and offers output voltages of 5V, 12V, 24V and 48V.

LI120-20BxxPR2 series features 4000VAC isolation test voltage and withstand 300VAC surge input for 5s. EMC meets the requirements of IEC61000 Class 4 and EMI(without peripheral components) meets the standards of CISPR32 Class A. It also meets IEC/EN/UL62368, IEC/EN/UL60335, GB4943 and UL508 safety standards. In addition, it can be installed in 5000m altitude environment. Protections of output short circuit, over-current, over-voltage, over-temperature are included.

Applications of Power Supply Series LI120-20BxxR2

Widely used in applications of industrial control, LED, street lamp control, power grid, security, communication, smart home, etc.

Typical application: Display screen of numerical control tool

Applications of Power Supply Series LI120-20BxxR2

Applications of Power Supply Series LI120-20BxxR2

LI120-20BxxR2 advantages in the display screen of numerical control tool:

● Compact size with standard DIN-Rail package, limited space requirement, easy to install

● Power up to 120Watt ensures the power supply for the back-end units

● 4Kv isolation voltage and excellent ripple & noise ensure the reliability of the whole power system

Features of Power Supply Series LI120-20BxxR2

● Universal 90-264VAC/127-370VDC input voltage(withstand 300VAC surge input for 5s)

● Operating temperature range of -20℃ to +60℃

● Isolation voltage:4000VAC

● Compact size: 35*125*112.7mm

● Regulated output, low ripple & noise as low as 150mV

● Cooling by free air convection

● Output short circuit, over-current, over-voltage, over-temperature protection

● Withstand 5G vibration test

● High efficiency, high reliability, long lifespan

● Meets 5000m altitude requirements


● Safety according to IEC/EN/UL62368, IEC/EN/UL60335, GB4943 and UL508(CE pending)

● Meets IEC/EN60335-1(PD3) and IEC/EN61558-1, 2-16 standards, suitable for household appliance applications

● 3 years warranty

* For detailed information please refer to the related datasheet, product news is for reference only.
Please refer to the technical manual for specific product parameters:

Series Power(W) Vin(VAC) Vin(VDC) Vout(VDC) Iout No. of Outputs Isolation Dimension(mm) Footprint & 3D Markings Datasheet Sample Buy
LI120-20B12R2 120 85-264 120-370 12 10A 1 4000VAC 35.00*125.00*112.7
LI120-20B24R2 120 85-264 120-370 24 5A 1 4000VAC 35.00*125.00*112.7
LI120-20B48R2 120 85-264 120-370 48 2.5A 1 4000VAC 35.00*125.00*112.7
