Mornsun launches the 5W ultra-compact cost-effective AC/DC converter LD05-23BxxR2P series after the 3W product LD03. This series features a compact size of 37.5*21*19mm, high reliability, high cost-effective, stable performance at a low temperature, and which is designed to meet OVC III (EN61558-1). It is ideal for the higher requirement on low cost and limited space.


1. Advantages of 5W Ultra-Compact Cost-effective AC/DC Converter

① Ultra-compact layout:

37.5*21*19mm, compatible with the 3W series pin-out, the long-narrow ac dc converter design suitable for the space limited requirement.

② Ultra-wide input voltage range:

85-305VAC / 100-430VDC, AC-DC dual-use, meet the universal voltage range.

③ Wide operating temperature range:

-40℃ to +85℃, meets the altitude requirements of 5000m and the environmental requirements of extremely low temperature and poor ventilation conditions.

④ High reliability

a. High isolation voltage up to 4200VAC

b. Meet IEC/EN/UL62368/EN60335/EN61558(OVC III) standards

c. Outstanding EMS performance: RS meets CISPR32/EN55032 CLASS B, and CS meets IEC/EN61000-4-6 10Vr.m.s Perf. Criteria A


2. Applications of 5W Ultra-Compact Cost-effective AC/DC Converter

It can be widely used in industrial control system, smart home, smart building, smart agriculture, household appliance, etc. especially for the high requirements of size and EMI.

LD05-23BxxR2P Series Typical applications.jpg


3. Features of LD05-23BxxR2P Series AC/DC Converter

  • No-load power consumption as low as 0.1W

  • High power density, and high efficiency up to 82%

  • Ultra-wide input voltage range: 85-305VAC / 100-430VDC, AC-DC dual-use, meet the different region grid voltages of 110VAC, 220VAC, 240VAC, 277VAC.

  • Wide operating temperature range: -40℃ to +85℃, meets the altitude requirements of 5000m and the environmental requirements of extremely low temperature and poor ventilation conditions.

  • High isolation voltage up to 4200VAC

  • Output short circuit and over-current protection

  • Meet IEC/EN/UL62368/EN60335/EN61558(OVC III) standards

* For detailed information please refer to the related datasheet, product news is for reference only.
Please refer to the technical manual for specific product parameters:

Series Power(W) Vin(VAC) Vin(VDC) Vout(VDC) Iout No. of Outputs Isolation Package Dimension(mm) Footprint & 3D Markings Datasheet Sample Buy
LD05-23B03R2P 3.3 85-305 100-430 3.3 1000mA 1 4200VAC DIP 37.50*21.00*19.00
LD05-23B05R2P 5 85-305 100-430 5 1000mA 1 4200VAC DIP 37.50*21.00*19.00
LD05-23B09R2P 5 85-305 100-430 9 555mA 1 4200VAC DIP 37.50*21.00*19.00
LD05-23B12R2P 5 85-305 100-430 12 416mA 1 4200VAC DIP 37.50*21.00*19.00
LD05-23B15R2P 5 85-305 100-430 15 333mA 1 4200VAC DIP 37.50*21.00*19.00
LD05-23B24R2P 5 85-305 100-430 24 208mA 1 4200VAC DIP 37.50*21.00*19.00
