Cost-effective Ultra-compact Non-isolated DC/DC switching regulator K78xx(JT)-500R3-LB Series

MORNSUN non-isolated DC/DC switching regulator K78xxJT-500R3-LB K78xx-500R3-LB.jpg


MORNSUN newly non-isolated DC/DC switching regulator K78xxJT-500R3-LB and K78xx-500R3-LB with ultra-compact size and good performance are the ideal solution to replace customers' self-built solutions, reduce design costs, improve design efficiency and make the overall system more reliable.


These modules feature a wide input voltage range of 4.75-36Vdc, operating temperature of -40℃~+85℃, no-load input current as low as 0.2mA, efficiency up to 95%, short circuit protection, and meet EN 62368 standard. Packages of SMD and SIP are available.


Application

K78xxJT-500R3-LB and K78xx-500R3-LB series can be widely used in industrial control, electric power, instrumentation and other industries.


MORNSUN non-isolated DC/DC switching regulator K78_LB.jpg


Features

● Efficiency up to 95%

● No-load input current as low as 0.2mA
● Operating temperature range: -40℃ to +85℃
● Output short-circuit protection

● Compact size

● Support the negative output (SIP package)

● Automatic production ensures product consistency

● Meet EN62368 standards

Please refer to the technical manual for specific product parameters:

Series Vin(VDC) Vout(VDC) Iout(mA) No. of Outputs Package Dimension(mm) Footprint & 3D Certification Datasheet Sample Buy
K7803-500R3-LB 24,12 ±3.3 500,-300 1 SIP 10.27*6.00*8.61
K7803JT-500R3-LB 24 3.3 500 1 - 12*12*4.5
K7805-500R3-LB 24,12 ±5 500,-300 1 SIP 10.27*6.00*8.61
K7805JT-500R3-LB 24 5 500 1 - 12*12*4.5
K7809-500R3-LB 24,12 ±9 500,-150 1 SIP 10.27*6.00*8.61
K7809JT-500R3-LB 24 9 500 1 - 12*12*4.5
K7812-500R3-LB 24,12 ±12 500,-150 1 SIP 10.27*6.00*8.61
K7812JT-500R3-LB 24 12 500 1 - 12*12*4.5
K7815-500R3-LB 24,12 ±15 500,-150 1 SIP 10.27*6.00*8.61
K7815JT-500R3-LB 24 15 500 1 - 12*12*4.5
K78X6-500R3-LB 24,12 ±6.5 500,-300 1 SIP 10.27*6.00*8.61
K78X6JT-500R3-LB 24 6.5 500 1 - 12*12*4.5
