45-65W High Power Density Medical-Grade AC-DC Converters—LO45/65-20BxxMU(-C) Series

45-65W High Power Density ACDC Specialized For Medical Power—LO4565-20BxxMU(-C) series.jpg


MORNSUN newly launched the miniaturized open-frame power supply—LO45/65-20BxxMU(-C), suitable for use in BF-type medical device. The series meets the medical certification standards and has the advantages of universal input voltage range, AC and DC dual-use, high efficiency up to 91%, leakage current as low as 75μA, etc., which makes it high reliability and cost-effective.


1. Advantages of LO45/65-20BxxMU(-C) series

1)  Universal input voltage range

85-264VAC(100-370VDC), AC and DC dual-use

2)  Meets the medical certification standards

a. Meets UL/IEC/EN60601 standards (fourth edition) (pending)

b. Leakage current as low as 75μA

c. Meets 2 x MOPP safety certification

d. Design meets UL/IEC/EN62368, IEC/EN60335-1, IEC/EN61558-1, GB4943-1 standards

3)  Compact size

a. LO45/65-20BxxMU: compact size of 3”x 2”x 1.03”

b. Shell series: LO45/65-20BxxMU-C

4)  Wide operating temperature range, high efficiency

a. Wide operating temperature range: -40℃ to +70℃

b. Efficiency up to 91%


2. Applications of LO45/65-20BxxMU(-C) series

High reliability design for the medical industry, which can be extended to industrial control, LED, street lighting control, electric power, security, telecommunication, smart home and other fields.


Applications of LO45/65-20BxxMU(-C) series.jpg


3. Features of LO45/65-20BxxMU(-C) series

●  Universal voltage: 85 - 264VAC/100 - 370VDC

●  High power density, compact size: 3”x 2”x 1.03”

●  Operating temperature range: -40℃ to +70℃

●  4000VAC high isolation voltage

●  Meets 5000m altitude application

●  Extremely low leakage current<75μA

●  No-load power consumption <0.3W

●  Multiple protections of output short-circuit, over-current and over-voltage

●  Efficiency up to 91%

●  Meets 2 x MOPP safety certification

●  Suitable for BF applications (higher leakage current requirements)

●  Meets EC/EN/ES60601-1, UL/EN/IEC62368-1, IEC/EN60335-1, IEC/EN61558-1, GB4943-1 standards


* For detailed information please refer to the related datasheet, product news is for reference only.
Please refer to the technical manual for specific product parameters:

Series Power(W) Vin(VAC) Vin(VDC) Vout(VDC) Iout No. of Outputs Isolation Package Dimension(mm) Footprint & 3D Markings Datasheet Sample Buy
LO45-20B03MU 26.4 85-264 100-370 3.3 8A 1 4000VAC Open frame 76.20*50.80*26.50
LO45-20B03MU-C 26.4 85-264 100-370 3.3 8A 1 4000VAC Enclosed 91.40*60.50*33.30
LO45-20B05MU 40 85-264 100-370 5 8A 1 4000VAC Open frame 76.20*50.80*26.50
LO45-20B05MU-C 40 85-264 100-370 5 8A 1 4000VAC Enclosed 91.40*60.50*33.30
LO45-20B12MU 45 85-264 100-370 12 3.75A 1 4000VAC Open frame 76.20*50.80*26.50
LO45-20B12MU-C 45 85-264 100-370 12 3.75A 1 4000VAC Enclosed 91.40*60.50*33.30
LO45-20B15MU 45 85-264 100-370 15 3A 1 4000VAC Open frame 76.20*50.80*26.50
LO45-20B15MU-C 45 85-264 100-370 15 3A 1 4000VAC Enclosed 91.40*60.50*33.30
LO45-20B24MU 45 85-264 100-370 24 1.875A 1 4000VAC Open frame 76.20*50.80*26.50
LO45-20B24MU-C 45 85-264 100-370 24 1.875A 1 4000VAC Enclosed 91.40*60.50*33.30
LO45-20B30MU 45 85-264 100-370 30 1.5A 1 4000VAC Chassis 76.20*50.80*26.50
LO45-20B30MU-C 45 85-264 100-370 30 1.5A 1 4000VAC Enclosed 91.40*60.50*33.30
LO45-20B36MU 45 85-264 100-370 36 1.25A 1 4000VAC Open frame 76.20*50.80*26.50
LO45-20B36MU-C 45 85-264 100-370 36 1.25A 1 4000VAC Enclosed 91.40*60.50*33.30
LO45-20B48MU 45 85-264 100-370 48 0.94A 1 4000VAC Open frame 76.20*50.80*26.50
LO45-20B48MU-C 45 85-264 100-370 48 0.94A 1 4000VAC Enclosed 91.40*60.50*33.30
LO65-20B03MU 33 85-264 100-370 3.3 10A 1 4000VAC Open frame 76.20*50.80*26.50
LO65-20B03MU-C 65 85-264 100-370 3.3 10A 1 4000VAC Enclosed 91.40*60.50*33.30
LO65-20B05MU 50 85-264 100-370 5 10A 1 4000VAC Open frame 76.20*50.80*26.50
LO65-20B05MU-C 50 85-264 100-370 5 10A 1 4000VAC Enclosed 91.40*60.50*33.30
LO65-20B12MU 65 85-264 100-370 12 5.42A 1 4000VAC Open frame 76.20*50.80*26.50
LO65-20B12MU-C 65 85-264 100-370 12 5.42A 1 4000VAC Enclosed 91.40*60.50*33.30
LO65-20B15MU 65 85-264 100-370 15 4.34A 1 4000VAC Open frame 76.20*50.80*26.50
LO65-20B15MU-C 65 85-264 100-370 15 4.34A 1 4000VAC Enclosed 91.40*60.50*33.30
LO65-20B24MU 65 85-264 100-370 24 2.71A 1 4000VAC Open frame 76.20*50.80*26.50
LO65-20B24MU-C 65 85-264 100-370 24 2.71A 1 4000VAC Enclosed 91.40*60.50*33.30
LO65-20B36MU 65 85-264 100-370 36 1.81A 1 4000VAC Open frame 76.20*50.80*26.50
LO65-20B36MU-C 65 85-264 100-370 36 1.81A 1 4000VAC Enclosed 91.40*60.50*33.30
LO65-20B48MU 65 85-264 100-370 48 1.36A 1 4000VAC Open frame 76.20*50.80*26.50
LO65-20B48MU-C 65 85-264 100-370 48 1.36A 1 4000VAC Enclosed 91.40*60.50*33.30
