WRA_S-1WR2

Features

WRA_S-1WR2 series are isolated 1W DC-DC products with 2:1 input voltage and conventional voltage output. The product has a relatively compact SIP-8 plastic package, and features high efficiency, operating temperature of -40℃ to +85℃, remote control, and continuous short-circuit protection. The smaller size and fine cost design make the converter an ideal solution in communication, instruments, and industrial electronics applications.

WRA_S-1WR2
MORE
数据加载中

Swipe to view all →
Product No. Power(W) Vin(VDC) Vout(VDC) No. of Outputs Isolation(VDC) Package Dimension(mm) Footprint & 3D Certification Datasheet Sample Buy
WRA0505S-1WR2 1 4.5~9 ±5 2 1500 SIP 22.0*9.5*12.0 3D MODEL CE - WRA0505S-1WR2 - sample request buy on line
WRA0512S-1WR2 1 4.5~9 ±12 2 1500 SIP 22.0*9.5*12.0 3D MODEL CE - WRA0512S-1WR2 - sample request buy on line
WRA0515S-1WR2 1 4.5~9 ±15 2 1500 SIP 22.0*9.5*12.0 3D MODEL CE - WRA0515S-1WR2 - sample request buy on line
WRA1205S-1WR2 1 9~18 ±5 2 1500 SIP 22.0*9.5*12.0 3D MODEL CE - WRA1205S-1WR2 - sample request buy on line
WRA1212S-1WR2 1 9~18 ±12 2 1500 SIP 22.0*9.5*12.0 3D MODEL CE - WRA1212S-1WR2 - sample request buy on line
WRA1215S-1WR2 1 9~18 ±15 2 1500 SIP 22.0*9.5*12.0 3D MODEL CE - WRA1215S-1WR2 - sample request buy on line
WRA2405S-1WR2 1 18~36 ±5 2 1500 SIP 22.0*9.5*12.0 3D MODEL CE - WRA2405S-1WR2 - sample request buy on line
WRA2409S-1WR2 1 18~36 ±9 2 1500 SIP 22.0*9.5*12.0 3D MODEL CE - WRA2409S-1WR2 - sample request buy on line
WRA2412S-1WR2 1 18~36 ±12 2 1500 SIP 22.0*9.5*12.0 3D MODEL CE - WRA2412S-1WR2 - sample request buy on line
WRA2415S-1WR2 1 18~36 ±15 2 1500 SIP 22.0*9.5*12.0 3D MODEL CE - WRA2415S-1WR2 - sample request buy on line
WRA4805S-1WR2 1 36~75 ±5 2 1500 SIP 22.0*9.5*12.0 3D MODEL CE - WRA4805S-1WR2 - sample request buy on line
WRA4812S-1WR2 1 36~75 ±12 2 1500 SIP 22.0*9.5*12.0 3D MODEL CE - WRA4812S-1WR2 - sample request buy on line
WRA4815S-1WR2 1 36~75 ±15 2 1500 SIP 22.0*9.5*12.0 3D MODEL CE - WRA4815S-1WR2 - sample request buy on line

* For reference only. The detailed info please refer to the datasheet.

Product No.
WRA0505S-1WR2
WRA0512S-1WR2
WRA0515S-1WR2
WRA1205S-1WR2
WRA1212S-1WR2
WRA1215S-1WR2
WRA2405S-1WR2
WRA2409S-1WR2
WRA2412S-1WR2
WRA2415S-1WR2
WRA4805S-1WR2
WRA4812S-1WR2
WRA4815S-1WR2
