URF48_QB-100W(F/H)R3
Our product's UL certification after May 1, 2024, is currently invalid. We are working diligently to resolve this. We apologize and appreciate your understanding.
Features
(H)R3(A5)(A6).jpg)
| Product No. | Power(W) | Vin(VDC) | Vout(VDC) | No. of Outputs | Isolation | Package | Dimension(mm) | Footprint & 3D | Markings | Datasheet | Sample |
| URF4805QB-100WR3 | 100 | 48(18-75) | 5 | 1 | 2250VDC | DIP | 61.80*40.20*12.70 | ||||
| URF4812QB-100WR3 | 100 | 48(18-75) | 12 | 1 | 2250VDC | DIP | 61.80*40.20*12.70 | ||||
| URF4815QB-100WR3 | 100 | 48(18-75) | 15 | 1 | 2250VDC | DIP | 61.80*40.20*12.70 | ||||
| URF4824QB-100WR3 | 100 | 48(18-75) | 24 | 1 | 2250VDC | DIP | 61.80*40.20*12.70 | ||||
| URF4848QB-100WR3 | 100 | 48(18-75) | 48 | 1 | 2250VDC | DIP | 61.80*40.20*12.70 | ||||
| URF4805QB-100WFR3 | 100 | 48(18-75) | 5 | 1 | 2250VDC | DIP | 62.0*56.0*14.6 | ||||
| URF4812QB-100WFR3 | 100 | 48(18-75) | 12 | 1 | 2250VDC | DIP | 62.0*56.0*14.6 | ||||
| URF4815QB-100WFR3 | 100 | 48(18-75) | 15 | 1 | 2250VDC | DIP | 62.0*56.0*14.6 | ||||
| URF4824QB-100WFR3 | 100 | 48(18-75) | 24 | 1 | 2250VDC | DIP | 62.0*56.0*14.6 | ||||
| URF4848QB-100WFR3 | 100 | 48(18-75) | 48 | 1 | 2250VDC | DIP | 62.0*56.0*14.6 | ||||
| URF4805QB-100WHR3 | 100 | 48(18-75) | 5 | 1 | 2250VDC | DIP | 61.8*40.2*27.7 | ||||
| URF4812QB-100WHR3 | 100 | 48(18-75) | 12 | 1 | 2250VDC | DIP | 61.8*40.2*27.7 | ||||
| URF4815QB-100WHR3 | 100 | 48(18-75) | 15 | 1 | 2250VDC | DIP | 61.8*40.2*27.7 | ||||
| URF4824QB-100WHR3 | 100 | 48(18-75) | 24 | 1 | 2250VDC | DIP | 61.8*40.2*27.7 | ||||
| URF4848QB-100WHR3 | 100 | 48(18-75) | 48 | 1 | 2250VDC | DIP | 61.8*40.2*27.7 | ||||
| URF4803QB-100WR3 | 100 | 48(18-75) | 3.3 | 1 | 2250VDC | DIP | 61.80*40.20*12.70 | - | |||
| URF4803QB-100WFR3 | 100 | 48(18-75) | 3.3 | 1 | 2250VDC | DIP | 62.0*56.0*14.6 | - | |||
| URF4803QB-100WHR3 | 100 | 48(18-75) | 3.3 | 1 | 2250VDC | DIP | 61.8*40.2*27.7 | - | |||
| URF4803QB-100WR3A5 | 100 | 48(19-75) | 3.3 | 1 | 2250VDC | DIP | 135.00* 70.00 * 22.60 | - | - | ||
| URF4803QB-100WR3A6 | 100 | 48(19-75) | 3.3 | 1 | 2250VDC | DIP | 137.00 * 70.00 * 28.10 | - | - | ||
| URF4803QB-100WHR3A5 | 100 | 48(19-75) | 3.3 | 1 | 2250VDC | DIP | 135.00 * 70.00 * 27.70 | - | - | ||
| URF4803QB-100WHR3A6 | 100 | 48(19-75) | 3.3 | 1 | 2250VDC | DIP | 137.00 * 70.00 * 37.2 | - | - | ||
| URF4805QB-100WR3A5 | 100 | 48(19-75) | 5 | 1 | 2250VDC | DIP | 135.00* 70.00 * 22.60 | - | |||
| URF4805QB-100WR3A6 | 100 | 48(19-75) | 5 | 1 | 2250VDC | DIP | 137.00 * 70.00 * 28.10 | - | |||
| URF4805QB-100WHR3A5 | 100 | 48(19-75) | 5 | 1 | 2250VDC | DIP | 135.00 * 70.00 * 27.70 | - | |||
| URF4805QB-100WHR3A6 | 100 | 48(19-75) | 5 | 1 | 2250VDC | DIP | 137.00 * 70.00 * 37.2 | - | |||
| URF4812QB-100WR3A5 | 100 | 48(19-75) | 12 | 1 | 2250VDC | DIP | 135.00* 70.00 * 22.60 | - | |||
| URF4812QB-100WR3A6 | 100 | 48(19-75) | 12 | 1 | 2250VDC | DIP | 137.00 * 70.00 * 28.10 | - | |||
| URF4812QB-100WHR3A5 | 100 | 48(19-75) | 12 | 1 | 2250VDC | DIP | 135.00 * 70.00 * 27.70 | - | |||
| URF4812QB-100WHR3A6 | 100 | 48(19-75) | 12 | 1 | 2250VDC | DIP | 137.00 * 70.00 * 37.2 | - | |||
| URF4815QB-100WR3A5 | 100 | 48(19-75) | 15 | 1 | 2250VDC | DIP | 135.00* 70.00 * 22.60 | - | |||
| URF4815QB-100WR3A6 | 100 | 48(19-75) | 15 | 1 | 2250VDC | DIP | 137.00 * 70.00 * 28.10 | - | |||
| URF4815QB-100WHR3A5 | 100 | 48(19-75) | 15 | 1 | 2250VDC | DIP | 135.00 * 70.00 * 27.70 | - | |||
| URF4815QB-100WHR3A6 | 100 | 48(19-75) | 15 | 1 | 2250VDC | DIP | 137.00 * 70.00 * 37.2 | - | |||
| URF4824QB-100WR3A5 | 100 | 48(19-75) | 24 | 1 | 2250VDC | DIP | 135.00* 70.00 * 22.60 | - | |||
| URF4824QB-100WR3A6 | 100 | 48(19-75) | 24 | 1 | 2250VDC | DIP | 137.00 * 70.00 * 28.10 | - | |||
| URF4824QB-100WHR3A5 | 100 | 48(19-75) | 24 | 1 | 2250VDC | DIP | 135.00 * 70.00 * 27.70 | - | |||
| URF4824QB-100WHR3A6 | 100 | 48(19-75) | 24 | 1 | 2250VDC | DIP | 137.00 * 70.00 * 37.2 | - | |||
| URF4848QB-100WR3A5 | 100 | 48(19-75) | 48 | 1 | 2250VDC | DIP | 135.00* 70.00 * 22.60 | - | |||
| URF4848QB-100WR3A6 | 100 | 48(19-75) | 48 | 1 | 2250VDC | DIP | 137.00 * 70.00 * 28.10 | - | |||
| URF4848QB-100WHR3A5 | 100 | 48(19-75) | 48 | 1 | 2250VDC | DIP | 135.00 * 70.00 * 27.70 | - | |||
| URF4848QB-100WHR3A6 | 100 | 48(19-75) | 48 | 1 | 2250VDC | DIP | 137.00 * 70.00 * 37.2 | - |
* For reference only. The detailed info please refer to the datasheet.
