URF2424QB-150W(F/H)R3(A5/A6)
Our product's UL certification after May 1, 2024, is currently invalid. We are working diligently to resolve this. We apologize and appreciate your understanding.
Features
URF2424QB-150W(F/H)R3(A5/A6)ofisolated150WDC-DCproductwithultra-wide4:1inputvoltage.Itfeaturesefficiencyupto89%, 2250VDCinputtooutputisolation,operatingambienttemperatureof-45℃to+85℃,inputunder-voltage,outputover–voltage,over-current, short-circuitprotection,over-temperatureprotection.TheproductsmeetCLASSAofCISPR32/EN55032EMIstandardsbyaddingthe recommendedexternalcomponents,andtheyarewidelyusedinapplicationssuchasbatterypoweredsystems,industrialcontrols,electricity, instrumentation,railway,communicationandintelligentrobotic
| Product No. | Power(W) | Vin(VDC) | Vout(VDC) | No. of Outputs | Isolation | Package | Dimension(mm) | Footprint & 3D | Markings | Datasheet | Sample |
| URF2424QB-150WR3 | 150 | 24(9-36) | 24 | 1 | 2250VDC | DIP | 61.8*40.2*12.7 | - | |||
| URF2424QB-150WFR3 | 150 | 24(9-36) | 24 | 1 | 2250VDC | DIP | 62.0*56.0*14.6 | - | |||
| URF2424QB-150WHR3 | 150 | 24(9-36) | 24 | 1 | 2250VDC | DIP | 61.8*40.2*27.7 | - |
* For reference only. The detailed info please refer to the datasheet.
