LS01-15BxxSS(-F)

Features

LS01-15BxxSS series is one of Mornsun's highly efficient green power AC-DC Converter series. They feature ultra-wide wide input range accepting either AC or DC voltage, high efficiency, low power consumption and CLASS II reinforced insulation. All models are particularly suitable for industrial control, electric power, instrumentation and smart home applications which don’t have high requirement for dimension. A variety of EMC external circuits meet the needs of multiple industries.

MORE
Loading...

Swipe to view all →
Product No. Power(W) Vin(VAC) Vout(VDC) No. of Outputs Isolation(VAC) Package Dimension(mm) Footprint & 3D Certification Datasheet Sample Buy
LS01-15B05SS 1 85-305VAC/70-430VDC 5 1 3000 SIP 35.0*18.0*11.0
LS01-15B05SS-F 1 85-305VAC/70-430VDC 5 1 3000 PCB mounting 35.0*18.0*11.0
LS01-15B09SS 1 85-305VAC/70-430VDC 9 1 3000 SIP 35.0*18.0*11.0
LS01-15B09SS-F 1 85-305VAC/70-430VDC 9 1 3000 PCB mounting 35.0*18.0*11.0
LS01-15B12SS 1 85-305VAC/70-430VDC 12 1 3000 SIP 35.0*18.0*11.0
LS01-15B12SS-F 1 85-305VAC/70-430VDC 12 1 3000 PCB mounting 35.0*18.0*11.0
LS01-15B15SS 1 85-305VAC/70-430VDC 15 1 3000 SIP 35.0*18.0*11.0
LS01-15B15SS-F 1 85-305VAC/70-430VDC 15 1 3000 PCB mounting 35.0*18.0*11.0
LS01-15B24SS 1 85-305VAC/70-430VDC 24 1 3000 SIP 35.0*18.0*11.0
LS01-15B24SS-F 1 85-305VAC/70-430VDC 24 1 3000 PCB mounting 35.0*18.0*11.0

* For reference only. The detailed info please refer to the datasheet.
