LH10-23B05/12R2-C
Features
LH10-23B05/12R2-CAC-DCconvertersarehighlyefficient,environmental-friendly10Wpowermodules.ItfeaturesuniversalACinputandat thesametimeacceptsDCinputvoltage,lowpowerconsumption,highefficiency,highreliability,reinforcedisolation.ItoffersgoodEMC performancecomplianttoIEC/EN61000-4andCISPR32/EN55032andmeetsIEC/EN/UL62368standards.Theconvertersarewidelyusedin industrial,powerandofficeapplications.ForextremelyharshEMCenvironment,werecommendusingtheapplicationcircuitshowin DesignReferenceofthisdatasheet.
| Product No. | Power(W) | Vin(VAC) | Vin(VDC) | Vout(VDC) | Iout | No. of Outputs | Isolation | Package | Dimension(mm) | Footprint & 3D | Markings | Datasheet | Sample | Buy |
| LH10-23B05R2-C | 10 | 85-305 | 100-430 | 5 | 2000mA | 1 | 4200VAC | DIP | 55.00*45.00*21.00 | |||||
| LH10-23B12R2-C | 10 | 85-305 | 100-430 | 12 | 900mA | 1 | 4200VAC | DIP | 55.00*45.00*21.00 |
* For reference only. The detailed info please refer to the datasheet.
