Medical and Healthcare, industry, smart building design requires robust power supply delivery, creating a growing demand for compact, high efficient, reliable and economical AC/DC converters. In response, MORNSUN launches its new generation medical grade compact open-frame AC/DC converter LOF series , which are medical, industry and household certified.

With compact size(4''×2''×1''), active PFC, high isolation voltage of 4000VAC and very low leakage current ( < 0.1mA), while meeting 2 x MOPP level, LOF series ensure high safety and reliability. These features make it an ideal or optimal solution for various applications, especially for the medical and healthcare sector.

LOF series characteristics & APPLICATION

Selection Guide

There are 96 results in total. Please see the list as below.
Loading...
Swipe to view all →
Product No. Power(W) Vin(VAC) Nominal Vout and Io(V/A) Operating Temperature Efficiency(%) Isolation(VAC) Certification Datasheet Sample Buy
LOF120-20B12-C 114 85-264VAC/120-370VDC 12V/9.5A -40℃ to +85℃ 94 4000 CE UL - sample request buy on line
LOF120-20B15-C 114 85-264VAC/120-370VDC 15V/7.6A -40℃ to +85℃ 94 4000 CE UL - sample request buy on line
LOF120-20B12-C 114 85-264VAC/120-370VDC 12V/9.5A -40℃ to +85℃ 94 4000 UL CE - sample request buy on line
LOF120-20B15-C 114 85-264VAC/120-370VDC 15V/7.6A -40℃ to +85℃ 94 4000 UL CE - sample request buy on line
LOF120-20B27-C 119.9 85-264VAC/120-370VDC 27V/4.44A -40℃ to +85℃ 95 4000 CE UL - sample request buy on line
LOF120-20B27-C 119.9 85-264VAC/120-370VDC 27V/4.44A -40℃ to +85℃ 95 4000 UL CE - sample request buy on line
LOF120-20B12 120 85-264VAC/120-370VDC 12V/9.5A -40℃ to +85℃ 94 4000 CE UL - sample request buy on line
LOF120-20B15 120 85-264VAC/120-370VDC 15V/7.6A -40℃ to +85℃ 94 4000 CE UL - sample request buy on line
LOF120-20B24 120 85-264VAC/120-370VDC 24V/5A -40℃ to +85℃ 95 4000 CE UL - sample request buy on line
LOF120-20B27 120 85-264VAC/120-370VDC 27V/4.44A -40℃ to +85℃ 95 4000 CE UL - sample request buy on line
LOF120-20B48 120 85-264VAC/120-370VDC 48V/2.5A -40℃ to +85℃ 94.5 4000 CE UL - sample request buy on line
LOF120-20B12 120 85-264VAC/120-370VDC 12V/9.5A -40℃ to +85℃ 94 4000 CE UL - sample request buy on line
LOF120-20B15 120 85-264VAC/120-370VDC 15V/7.6A -40℃ to +85℃ 94 4000 CE UL - sample request buy on line
LOF120-20B24 120 85-264VAC/120-370VDC 24V/5A -40℃ to +85℃ 95 4000 CE UL - sample request buy on line
LOF120-20B27 120 85-264VAC/120-370VDC 27V/4.44A -40℃ to +85℃ 95 4000 CE UL - sample request buy on line
LOF120-20B48 120 85-264VAC/120-370VDC 48V/2.5A -40℃ to +85℃ 94.5 4000 CE UL - sample request buy on line
LOF120-20B24-C 120 85-264VAC/120-370VDC 24V/5A -40℃ to +85℃ 95 4000 CE UL - sample request buy on line
LOF120-20B48-C 120 85-264VAC/120-370VDC 48V/2.5A -40℃ to +85℃ 94.5 4000 CE UL - sample request buy on line
LOF120-20B24-C 120 85-264VAC/120-370VDC 24V/5A -40℃ to +85℃ 95 4000 UL CE - sample request buy on line
LOF120-20B48-C 120 85-264VAC/120-370VDC 48V/2.5A -40℃ to +85℃ 94.5 4000 UL CE - sample request buy on line
LOF120-20B36 120 85-264VAC/120-370VDC 36V/3.33A -40℃ to +85℃ 94 4000 CE UL - sample request buy on line
LOF120-20B36-C 120 85-264VAC/120-370VDC 36V/3.33A -40℃ to +85℃ 94 4000 UL CE - sample request buy on line
LOF120-20B36 120 85-264VAC/120-370VDC 36V/3.33A -40℃ to +85℃ 94 4000 CE UL - sample request buy on line
LOF120-20B36-C 120 85-264VAC/120-370VDC 36V/3.33A -40℃ to +85℃ 94 4000 CE UL - sample request buy on line
LOF120-20B54 120 85-264VAC/120-370VDC 54V/2.22A -40℃ to +85℃ 94 4000 CE UL - sample request buy on line
LOF120-20B54-C 120 85-264VAC/120-370VDC 54V/2.22A -40℃ to +85℃ 94 4000 CE UL - sample request buy on line
LOF120-20B54 120 85-264VAC/120-370VDC 54V/2.22A -40℃ to +85℃ 94 4000 CE UL - sample request buy on line
LOF120-20B54-C 120 85-264VAC/120-370VDC 54V/2.22A -40℃ to +85℃ 94 4000 CE UL - sample request buy on line
LOF225-20B12 225 85-264VAC/120-370VDC 12V/18.75A -40℃ to +70℃ 93 4000 CE UL - sample request buy on line
LOF225-20B15 225 85-264VAC/120-370VDC 15V/15A -40℃ to +70℃ 93 4000 CE UL - sample request buy on line
LOF225-20B24 225 85-264VAC/120-370VDC 24V/9.4A -40℃ to +70℃ 94 4000 CE UL - sample request buy on line
LOF225-20B27 225 85-264VAC/120-370VDC 27V/8.35A -40℃ to +70℃ 94 4000 CE UL - sample request buy on line
LOF225-20B48 225 85-264VAC/120-370VDC 48V/4.7A -40℃ to +70℃ 94 4000 CE UL - sample request buy on line
LOF225-20B12 225 85-264VAC/120-370VDC 12V/18.75A -40℃ to +70℃ 93 4000 CE UL - sample request buy on line
LOF225-20B15 225 85-264VAC/120-370VDC 15V/15A -40℃ to +70℃ 93 4000 CE UL - sample request buy on line
LOF225-20B24 225 85-264VAC/120-370VDC 24V/9.4A -40℃ to +70℃ 94 4000 CE UL - sample request buy on line
LOF225-20B27 225 85-264VAC/120-370VDC 27V/8.35A -40℃ to +70℃ 94 4000 CE UL - sample request buy on line
LOF225-20B48 225 85-264VAC/120-370VDC 48V/4.7A -40℃ to +70℃ 94 4000 CE UL - sample request buy on line
LOF225-20B12-C 225 85-264VAC/120-370VDC 12V/18.75A -40℃ to +70℃ 93 4000 CE UL - sample request buy on line
LOF225-20B15-C 225 85-264VAC/120-370VDC 15V/15A -40℃ to +70℃ 93 4000 CE UL - sample request buy on line
LOF225-20B24-C 225 85-264VAC/120-370VDC 24V/9.4A -40℃ to +70℃ 94 4000 CE UL - sample request buy on line
LOF225-20B27-C 225 85-264VAC/120-370VDC 27V/8.35A -40℃ to +70℃ 94 4000 CE UL - sample request buy on line
LOF225-20B48-C 225 85-264VAC/120-370VDC 48V/4.7A -40℃ to +70℃ 94 4000 CE UL - sample request buy on line
LOF225-20B12-C 225 85-264VAC/120-370VDC 12V/18.75A -40℃ to +70℃ 93 4000 UL CE - sample request buy on line
LOF225-20B15-C 225 85-264VAC/120-370VDC 15V/15A -40℃ to +70℃ 93 4000 UL CE - sample request buy on line
LOF225-20B24-C 225 85-264VAC/120-370VDC 24V/9.4A -40℃ to +70℃ 94 4000 UL CE - sample request buy on line
LOF225-20B27-C 225 85-264VAC/120-370VDC 27V/8.35A -40℃ to +70℃ 94 4000 UL CE - sample request buy on line
LOF225-20B48-C 225 85-264VAC/120-370VDC 48V/4.7A -40℃ to +70℃ 94 4000 UL CE - sample request buy on line
LOF225-20B36 225 85-264VAC/120-370VDC 36V/6.25A -40℃ to +70℃ 93 4000 CE UL - sample request buy on line
LOF225-20B36-C 225 85-264VAC/120-370VDC 36V/6.25A -40℃ to +70℃ 94 4000 UL CE - sample request buy on line
LOF225-20B36 225 85-264VAC/120-370VDC 36V/6.25A -40℃ to +70℃ 93 4000 CE UL - sample request buy on line
LOF225-20B36-C 225 85-264VAC/120-370VDC 36V/6.25A -40℃ to +70℃ 94 4000 Pending - sample request buy on line
LOF225-20B54 225 85-264VAC/120-370VDC 54V/4.17A -40℃ to +70℃ 94 4000 CE UL - sample request buy on line
LOF225-20B54-C 225 85-264VAC/120-370VDC 54V/4.17A -40℃ to +70℃ 94 4000 UL CE - sample request buy on line
LOF225-20B54 225 85-264VAC/120-370VDC 54V/4.17A -40℃ to +70℃ 94 4000 CE UL - sample request buy on line
LOF225-20B54-C 225 85-264VAC/120-370VDC 54V/4.17A -40℃ to +70℃ 94 4000 CE UL - sample request buy on line
LOF350-20B12-C 300 90-264VAC/127-370VDC 12V/25A -40℃ to +70℃ 92 4000 UL CE - sample request buy on line
LOF350-20B12-C 300 90-264VAC/127-370VDC 12V/25A -40℃ to +70℃ 92 4000 CE UL - sample request buy on line
LOF350-20B15-C 325 90-264VAC/127-370VDC 15V/21.67A -40℃ to +70℃ 92 4000 UL CE - sample request buy on line
LOF350-20B15-C 325 90-264VAC/127-370VDC 15V/21.67A -40℃ to +70℃ 92 4000 CE UL - sample request buy on line
LOF350-20B12 350 90-264VAC/127-370VDC 12V/25A -40℃ to +70℃ 92 4000 UL CE - sample request buy on line
LOF350-20B15 350 90-264VAC/127-370VDC 15V/21.67A -40℃ to +70℃ 92 4000 UL CE - sample request buy on line
LOF350-20B24 350 90-264VAC/127-370VDC 24V/14.6A -40℃ to +70℃ 93 4000 UL CE - sample request buy on line
LOF350-20B27 350 90-264VAC/127-370VDC 27V/13A -40℃ to +70℃ 93 4000 UL CE - sample request buy on line
LOF350-20B48 350 90-264VAC/127-370VDC 48V/7.3A -40℃ to +70℃ 94 4000 UL CE - sample request buy on line
LOF350-20B12 350 90-264VAC/127-370VDC 12V/25A -40℃ to +70℃ 92 4000 UL CE - sample request buy on line
LOF350-20B15 350 90-264VAC/127-370VDC 15V/21.67A -40℃ to +70℃ 92 4000 UL CE - sample request buy on line
LOF350-20B24 350 90-264VAC/127-370VDC 24V/14.6A -40℃ to +70℃ 93 4000 CE UL - sample request buy on line
LOF350-20B27 350 90-264VAC/127-370VDC 27V/13A -40℃ to +70℃ 93 4000 CE UL - sample request buy on line
LOF350-20B48 350 90-264VAC/127-370VDC 48V/7.3A -40℃ to +70℃ 94 4000 UL CE - sample request buy on line
LOF350-20B36 350.28 90-264VAC/127-370VDC 36V/9.73A -40℃ to +70℃ 93 4000 CE - sample request buy on line
LOF350-20B36-C 350.28 90-264VAC/127-370VDC 36V/9.73A -40℃ to +70℃ 93 4000 CE - sample request buy on line
LOF350-20B36 350.28 90-264VAC/127-370VDC 36V/9.73A -40℃ to +70℃ 93 4000 UL - sample request buy on line
LOF350-20B36-C 350.28 90-264VAC/127-370VDC 36V/9.73A -40℃ to +70℃ 93 4000 UL - sample request buy on line
LOF350-20B24-C 350.4 90-264VAC/127-370VDC 24V/14.6A -40℃ to +70℃ 93 4000 UL CE - sample request buy on line
LOF350-20B48-C 350.4 90-264VAC/127-370VDC 48V/7.3A -40℃ to +70℃ 94 4000 UL CE - sample request buy on line
LOF350-20B24-C 350.4 90-264VAC/127-370VDC 24V/14.6A -40℃ to +70℃ 93 4000 CE UL - sample request buy on line
LOF350-20B48-C 350.4 90-264VAC/127-370VDC 48V/7.3A -40℃ to +70℃ 94 4000 CE UL - sample request buy on line
LOF350-20B27-C 351 90-264VAC/127-370VDC 27V/13A -40℃ to +70℃ 93 4000 UL CE - sample request buy on line
LOF350-20B27-C 351 90-264VAC/127-370VDC 27V/13A -40℃ to +70℃ 93 4000 CE UL - sample request buy on line
LOF350-20B54 351 90-264VAC/127-370VDC 54V/6.5A -40℃ to +70℃ 94 4000 Pending - sample request buy on line
LOF350-20B54-C 351 90-264 54V/6.5A -40℃ to +70℃ 94 4000 Pending - sample request buy on line
LOF350-20B54 351 90-264VAC/127-370VDC 54V/6.5A -40℃ to +70℃ 94 4000 Pending - sample request buy on line
LOF350-20B54-C 351 90-264VAC/127-370VDC 54V/6.5A -40℃ to +70℃ 94 4000 Pending - sample request buy on line
LOF450-20B12 400 90-264 12V/33.3 -40℃ to +70℃ 91 4000 Pending - sample request buy on line
LOF450-20B15 400 90-264 15V/26.7 -40℃ to +70℃ 92 4000 Pending - sample request buy on line
LOF450-20B24 450 90-264 24V/18.75 -40℃ to +70℃ 93 4000 Pending - sample request buy on line
LOF450-20B27 450 90-264 27V/16.7 -40℃ to +70℃ 93.5 4000 Pending - sample request buy on line
LOF450-20B36 450 90-264 36V/12.5 -40℃ to +70℃ 93 4000 Pending - sample request buy on line
LOF450-20B48 450 90-264 48V/9.4 -40℃ to +70℃ 94 4000 Pending - sample request buy on line
LOF550-20B12 499.2 90-264 12V/41.6 -40℃ to +70℃ 91 4000 Pending - sample request buy on line
LOF550-20B15 499.5 90-264 15V/33.3 -40℃ to +70℃ 92 4000 Pending - sample request buy on line
LOF550-20B24 549.6 90-264 24V/22.9 -40℃ to +70℃ 93 4000 Pending - sample request buy on line
LOF550-20B48 550 90-264 48V/11.46 -40℃ to +70℃ 94 4000 Pending - sample request buy on line
LOF550-20B27 550.8 90-264 27V/20.4 -40℃ to +70℃ 93.5 4000 Pending - sample request buy on line
LOF550-20B36 550.8 90-264 36V/15.3 -40℃ to +70℃ 93 4000 Pending - sample request buy on line

* For reference only. The detailed info please refer to the datasheet.
