40-60W High Power Density DC/DC Converter - URB24xxYMD-40WR3, URB24xxLD-60WR3 Series

40-60W High Power Density DC/DC Converter - URB24xxYMD-40WR3, URB24xxLD-60WR3 Series.jpg

Introduction

MORNSUN 40W/60W high power density DC/DC converters (URB24xxYMD-40WR3/URB24xxLD-60WR3 series) in the R3 series are designed to meet the higher requirements of compact size and wide input voltage, to cope with the rapid development of industrial power.


It features an ultra-wide input voltage range of 9-36V, a wide operating temperature range of -40℃ to +105℃, and has input under-voltage, output over-voltage, over-current, and short-circuit protection, which provides stable support for the backend.


Advantages

Fast and stable Delivery

MORNSUN has established 34+ SMT production lines, contributing to a production capacity of 150KK per year. With this strong production capacity, Mornsun provides a controllable and free from outside influence solution to ensure stable delivery, making it the ideal choice for reliability and cost-effectiveness.


Compact size & High power density

The modules feature high power density and compact size, effectively reducing the PCB footprint and improving space utilization.

URB24xxYMD-40WR3's dimension: 1*1, high power density up to 87W/ in3

URB24xxLD-60WR3's dimension: 2*1, high power density up to 65W/in3


Applications

URB24xxYMD-40WR3 and URB24xxLD-60WR3 series can be widely used in industrial control, electric power, instrumentation, and communication applications.

Typical Applications of industrial control, electric power, instrumentation, and communication applications.jpg


Features

  • Input voltage range: 24 (9-36) VDC

  • Output voltage range: 3.3-28VDC

  • High efficiency up to 93.3%

  • Operating temperature range: -40℃ to +105℃

  • No-load power consumption as low as 0.096W (URB24xxYMD-40WR3)

  • Input under-voltage protection

  • Output short-circuit, over-current, over-voltage, over-temperature protection

  • Universal industry standard pin-out

  • Meets EN62368 standard



* For detailed information please refer to the related datasheet, product news is for reference only.
Please refer to the technical manual for specific product parameters:

Series Power(W) Vin(VDC) Vout(VDC) No. of Outputs Isolation Package Dimension(mm) Footprint & 3D Markings Datasheet Sample Buy
URB2403YMD-40WR3 40 24(9-36) 3.3 1 1500VDC DIP 25.40 * 25.40 * 11.70
-
URB2405LD-60WHR3 60 24(9-36) 5 1 1500VDC DIP 51.40*26.20*16.50
-
URB2405LD-60WR3 60 24(9-36) 5 1 1500VDC DIP 50.80*25.40*11.80
-
URB2405YMD-40WR3 40 24(9-36) 5 1 1500VDC DIP 25.40 * 25.40 * 11.70
-
URB2412LD-60WHR3 60 24(9-36) 12 1 1500VDC DIP 51.40*26.20*16.50
-
URB2412LD-60WR3 60 24(9-36) 12 1 1500VDC DIP 50.80*25.40*11.80
-
URB2412YMD-40WR3 40 24(9-36) 12 1 1500VDC DIP 25.40 * 25.40 * 11.70
-
URB2415LD-60WHR3 60 24(9-36) 15 1 1500VDC DIP 51.40*26.20*16.50
-
URB2415LD-60WR3 60 24(9-36) 15 1 1500VDC DIP 50.80*25.40*11.80
-
URB2415YMD-40WR3 40 24(9-36) 15 1 1500VDC DIP 25.40 * 25.40 * 11.70
-
URB2424LD-60WHR3 60 24(9-36) 24 1 1500VDC DIP 51.40*26.20*16.50
-
URB2424LD-60WR3 60 24(9-36) 24 1 1500VDC DIP 50.80*25.40*11.80
-
URB2424YMD-40WR3 40 24(9-36) 24 1 1500VDC DIP 25.40 * 25.40 * 11.70
-
URB2428YMD-40WR3 40 24(9-36) 28 1 1500VDC DIP 25.40 * 25.40 * 11.70
-
