MORNSUN 15-600W AC/DC enclosed switching power supplies feature wide range of input voltage and operating temperature, excellent EMC performance, which is ideal for a wide range of applications such as industrial automation, instrumentation, IoT, LED, street light control, electricity, security, telecommunications, smart home, and medical, etc. These switching-mode power supplies withstand 300VAC surge input for 5s and meet IEC/EN61000-4, CISPR32/EN55032, IEC/UL/ EN62368, EN60335 and EN61558 standards. Check these cost-saving SMPS below.
LM Series
MORE
LM15/ LM25/ LM35/ LM50/ LM75/ LM100/ LM150/ LM200/
LM350 Non-PFC, Economical Models
- Compact size with 30mm thickness low profile
- Optional input: 85-305VAC/85-264VAC/165-264VAC
- Optional output: single output/ dual outputs/triple outputs
- Operating temperature: -30℃ to +70℃
- Withstand 300VAC input surge for 5s
- Standby power consumption < 0.3W
- Withstand 5G vibration test
- Meets 5000m altitude requirement
- IEC/EN60335-1(PD3), IEC/EN61558-1, -2-16
LMF/LOF Series
MORE
75~320W LMF Series, 120~350W LOF Series
Built-in active PFC function(up to 0.98PF)
- Universal input: 85-264VAC, accepts AC or DC input
- Operating temperature: -40℃ to +85℃
- Isolation voltage up to 4000VAC
- Leakage current < 0.1mA(for LOF)
- Remote ON-OFF control(for LMF)
- IEC/EN/UL62368, IEC/EN60335, IEC/EN61558(for LOF), IEC/EN/ES60601(for LOF)
- Emissions meets CISPR32/EN55032 CLASS B without extra components(for LMF)
- Conformal coating and terminal cover are optional(for LMF)/ The base plate with conformal coating(for LOF)
- 2 x MOPP safety level(for LOF)
WIDE SELECTION, RELIABLE PERFORMANCE
-
Optional Output
Accepts AC or DC input, single output, dual/triple outputs
-
Multiple Protections
SCP, OCP, OVP
-
Reliable Performance
Withstand 300VAC surge input for 5s,
Isolation up to 4000VAC -
Certifications
IEC/EN/UL62368, IEC/EN60335
-
Optional Input Range
Universal input: 85-305VAC or 85-264VAC
Special input: 165-264VAC -
High Efficiency
High efficiency up to 91.5%
Conformal coating is available -
Temperature & Altitude
Operating temperature: -30℃ to +70℃
Meets 5000m altitude requirements -
EMC Performance
EMI: CISPR32/EN55032 CLASS B
EMS: IEC/EN 61000
Selection Guide
There are 230 results in total. Please see the list as below.
| Product No. | Power(W) | Vin(VAC) | Nominal Vout and Io(V/A) | Operating Temperature | No. of Outputs | Efficiency(%) | Isolation(VAC) | Certification | Datasheet | Sample |
| LM15-23B03 | 9.9 | 85~305VAC/100~430VDC | 3.3V/3.0A | -30℃ to +70℃ | 1 | 83 | 4000 |
-
|
|
|
| LI30-20B05PR2 | 15 | 85~264 | - | - | 1 | - | 4000 |
-
|
|
|
| LM15-23B05 | 15 | 85~305VAC/100~430VDC | 5V/3.0A | -30℃ to +70℃ | 1 | 83 | 4000 |
-
|
|
|
| LM15-23B15 | 15 | 85~305VAC/100~430VDC | 15V/1.0A | -30℃ to +70℃ | 1 | 83 | 4000 |
-
|
|
|
| LM15-23B24 | 15 | 85~305VAC/100~430VDC | 24V/0.625A | -30℃ to +70℃ | 1 | 83 | 4000 |
-
|
|
|
| LM15-23B48 | 15.36 | 85~305VAC/100~430VDC | 48V/0.32A | -30℃ to +70℃ | 1 | 83 | 4000 |
-
|
|
|
| LM15-23B12 | 15.6 | 85~305VAC/100~430VDC | 12V/1.3A | -30℃ to +70℃ | 1 | 83 | 4000 |
-
|
|
|
| LM25-23B03 | 19.8 | 85~305VAC/100~430VDC | 3.3V/6A | -30℃ to +70℃ | 1 | 88 | 4000 |
-
|
|
|
| LI30-20B12PR2 | 24 | 85~264 | - | - | 1 | - | 4000 |
-
|
|
|
| LM25-23B05 | 25 | 85~305VAC/100~430VDC | 5V/5A | -30℃ to +70℃ | 1 | 88 | 4000 |
-
|
|
|
| LM25-23B12 | 25.2 | 85~305VAC/100~430VDC | 12V/2.1A | -30℃ to +70℃ | 1 | 88 | 4000 |
-
|
|
|
| LM25-23B15 | 25.5 | 85~305VAC/100~430VDC | 15V/1.7A | -30℃ to +70℃ | 1 | 88 | 4000 |
-
|
|
|
| LM25-23B24 | 26.4 | 85~305VAC/100~430VDC | 24V/1.1A | -30℃ to +70℃ | 1 | 88 | 4000 |
-
|
|
|
| LM25-23B48 | 27.36 | 85~305VAC/100~430VDC | 48V/0.57A | -30℃ to +70℃ | 1 | 88 | 4000 |
-
|
|
|
| LM30-00J0512-03E | 30 | 85~264VAC/100~370VDC | - | -40℃ to +70℃ | 4 | 83 | 2000 | - |
|
|
| LI30-20B15PR2 | 30 | 85~264 | - | - | 1 | - | 4000 |
-
|
|
|
| LM35-10D0512-10 | 32 | 85~264VAC/120~373VDC | 5V/4A,12V/1A | -30℃ to +70℃ | 2 | 81 | 3000 |
-
|
|
|
| LI60-20B05PR2 | 32.5 | 85~264 | - | - | 1 | - | 4000 |
-
|
|
|
| LM35-10C051212-10 | 33 | 85~264VAC/120~373VDC | 5V/3A,12V/1A,-12V/0.5A | -30℃ to +70℃ | 3 | 81 | 3000 |
-
|
|
|
| LM35-20B05 | 35 | 85~264VAC/120~373VDC | 5V/7A | -30℃ to +70℃ | 1 | 82 | 4000 |
-
|
|
|
| LM35-22B05 | 35 | 165~264VAC/180~373VDC | 5V/7A | -30℃ to +70℃ | 1 | 82 | 4000 |
-
|
|
|
| LM35-10C051515-10 | 35 | 85~264VAC/120~373VDC | 5V/2.5A,15V/1A,-15V/0.5A | -30℃ to +70℃ | 3 | 81 | 3000 |
-
|
|
|
| LM35-10D0524-10 | 35 | 85~264VAC/120~373VDC | 5V/2.2A,24V/1A | -30℃ to +70℃ | 2 | 83 | 3000 |
-
|
|
|
| LM35-23B05 | 35 | 85~305VAC/120~430VDC | 5V/7A | -30℃ to +70℃ | 1 | 81 | 4000 |
-
|
|
|
| LM35-20B12 | 36 | 85~264VAC/120~373VDC | 12V/3A | -30℃ to +70℃ | 1 | 86 | 4000 |
-
|
|
|
| LM35-20B15 | 36 | 85~264VAC/120~373VDC | 15V/2.4A | -30℃ to +70℃ | 1 | 87 | 4000 |
-
|
|
|
| LM35-20B24 | 36 | 85~264VAC/120~373VDC | 24V/1.5A | -30℃ to +70℃ | 1 | 88 | 4000 |
-
|
|
|
| LM35-22B12 | 36 | 165~264VAC/180~373VDC | 12V/3A | -30℃ to +70℃ | 1 | 86 | 4000 |
-
|
|
|
| LM35-22B15 | 36 | 165~264VAC/180~373VDC | 15V/2.4A | -30℃ to +70℃ | 1 | 87 | 4000 |
-
|
|
|
| LM35-22B24 | 36 | 165~264VAC/180~373VDC | 24V/1.5A | -30℃ to +70℃ | 1 | 88 | 4000 |
-
|
|
|
| LI30-20B24PR2 | 36 | 85~264 | - | - | 1 | - | 4000 |
-
|
|
|
| LI30-20B48PR2 | 36 | 85~264 | - | - | 1 | - | 4000 |
-
|
|
|
| LM35-22B12-DX | 36 | 165~264VAC/180~373VDC | 12V/3A | -30℃ to +70℃ | 1 | 86 | 4000 | - |
|
|
| LM35-23B12 | 36 | 85~305VAC/120~430VDC | 12V/3A | -30℃ to +70℃ | 1 | 85 | 4000 |
-
|
|
|
| LM35-23B15 | 36 | 85~305VAC/120~430VDC | 12V/3A | -30℃ to +70℃ | 1 | 86 | 4000 |
-
|
|
|
| LM35-23B24 | 36 | 85~305VAC/120~430VDC | 12V/3A | -30℃ to +70℃ | 1 | 87 | 4000 |
-
|
|
|
| LM35-10C052412-05 | 36.5 | 85~264VAC/120~373VDC | 5V/2.5A,24V/0.5A,12V/1A | -30℃ to +70℃ | 3 | 81 | 3000 |
-
|
|
|
| LM50-22B05 | 50 | 165~264VAC/180~373VDC | 5V/10A | -30℃ to +70℃ | 1 | 83 | 4000 |
-
|
|
|
| LM50-20B05 | 50 | 85~264VAC/120~373VDC | 5V/10A | -30℃ to +70℃ | 1 | 86 | 4000 |
-
|
|
|
| LM50-10C051212-20 | 50 | 85~264VAC/120~373VDC | 5V/4A,12V/2A,-12V/0.5A | -30℃ to +70℃ | 3 | 81 | 3000 |
-
|
|
|
| LM50-10C051515-15 | 50 | 85~264VAC/120~373VDC | 5V/4A,15V/1.5A,-15V/0.5A | -30℃ to +70℃ | 3 | 83 | 3000 |
-
|
|
|
| LM50-23B05 | 50 | 85~305VAC/120~430VDC | 5V/10A | -30℃ to +70℃ | 1 | 83 | 4000 |
-
|
|
|
| LM50-22B12 | 50.4 | 165~264VAC/180~373VDC | 12V/4.2A | -30℃ to +70℃ | 1 | 86 | 4000 |
-
|
|
|
| LM50-20B12 | 50.4 | 85~264VAC/120~373VDC | 12V/4.2A | -30℃ to +70℃ | 1 | 87 | 4000 |
-
|
|
|
| LM50-10A12 | 50.4 | 85~264VAC/120~373VDC | 12V/2.1A,-12V/2.1A | -30℃ to +70℃ | 2 | 83 | 3000 | - |
|
|
| LM50-23B12 | 50.4 | 85~305VAC/120~430VDC | 12V/4.2A | -30℃ to +70℃ | 1 | 86 | 4000 |
-
|
|
|
| LM50-22B15 | 51 | 165~264VAC/180~373VDC | 15V/3.4A | -30℃ to +70℃ | 1 | 87 | 4000 |
-
|
|
|
| LM50-20B15 | 51 | 85~264VAC/120~373VDC | 15V/3.4A | -30℃ to +70℃ | 1 | 88 | 4000 |
-
|
|
|
| LM50-10C052412-10 | 51 | 85~264VAC/120~373VDC | 5V/3A,24V/1A,12V/1A | -30℃ to +70℃ | 3 | 85 | 3000 |
-
|
|
|
| LM50-23B15 | 51 | 85~305VAC/120~430VDC | 15V/3.4A | -30℃ to +70℃ | 1 | 87 | 4000 |
-
|
|
|
| LM50-23B36 | 52.2 | 85~305VAC/120~430VDC | 36V/1.45A | -30℃ to +70℃ | 1 | 89 | 4000 |
-
|
|
|
| LM50-22B36 | 52.2 | 165~264VAC/180~373VDC | 36V/1.45A | -30℃ to +70℃ | 1 | 89 | 4000 |
-
|
|
|
| LM50-20B36 | 52.2 | 85~264VAC/120~373VDC | 36V/1.45A | -30℃ to +70℃ | 1 | 89 | 4000 |
-
|
|
|
| LM50-22B24 | 52.8 | 165~264VAC/180~373VDC | 24V/2.2A | -30℃ to +70℃ | 1 | 88 | 4000 |
-
|
|
|
| LM50-20B24 | 52.8 | 85~264VAC/120~373VDC | 24V/2.2A | -30℃ to +70℃ | 1 | 89 | 4000 |
-
|
|
|
| LM50-23B24 | 52.8 | 85~305VAC/120~430VDC | 24V/2.2A | -30℃ to +70℃ | 1 | 88 | 4000 |
-
|
|
|
| LM50-23B48 | 52.8 | 85~305VAC/120~430VDC | 48V/1.1A | -30℃ to +70℃ | 1 | 90 | 4000 |
-
|
|
|
| LM50-22B48 | 52.8 | 165~264VAC/180~373VDC | 48V/1.1A | -30℃ to +70℃ | 1 | 90 | 4000 |
-
|
|
|
| LM50-20B48 | 52.8 | 85~264VAC/120~373VDC | 48V/1.1A | -30℃ to +70℃ | 1 | 90 | 4000 |
-
|
|
|
| LM50-10D0524-14 | 53.6 | 85~264VAC/120~373VDC | 5V/4A,24V/1.4A | -30℃ to +70℃ | 2 | 84 | 3000 |
-
|
|
|
| LI60-20B12PR2 | 54 | 85~264 | - | - | 1 | - | 4000 |
-
|
|
|
| LM50-10D0512-20 | 54 | 85~264VAC/120~373VDC | 5V/6A,12V/2A | -30℃ to +70℃ | 2 | 83 | 3000 |
-
|
|
|
| LI60-20B15PR2 | 60 | 85~264 | - | - | 1 | - | 4000 |
-
|
|
|
| LI60-20B24PR2 | 60 | 85~264 | - | - | 1 | - | 4000 |
-
|
|
|
| LI60-20B48PR2 | 60 | 85~264 | - | - | 1 | - | 4000 |
-
|
|
|
| LM75-10C051212-28 | 69.6 | 90~264VAC/120~373VDC | 5V/6A,12V/2.8A,-12V/0.5A | -30℃ to +70℃ | 3 | 82 | 3000 |
-
|
|
|
| LM75-20B05 | 70 | 85~264VAC/120~373VDC | 5V/14A | -30℃ to +70℃ | 1 | 86 | 4000 |
-
|
|
|
| LM75-22B05 | 70 | 165~264VAC/200~373VDC | 5V/14A | -30℃ to +70℃ | 1 | 86 | 4000 |
-
|
|
|
| LM75-23B05 | 70 | 85~305VAC/120~430VDC | 5V/14A | -30℃ to +70℃ | 1 | 85 | 4000 |
-
|
|
|
| LM75-10D0512-30 | 71 | 90~264VAC/120~373VDC | 5V/7A,12V/3A | -30℃ to +70℃ | 2 | 82 | 3000 |
-
|
|
|
| LM75-20B12 | 72 | 85~264VAC/120~373VDC | 12V/6A | -30℃ to +70℃ | 1 | 88 | 4000 |
-
|
|
|
| LM75-22B12 | 72 | 165~264VAC/200~373VDC | 12V/6A | -30℃ to +70℃ | 1 | 88 | 4000 |
-
|
|
|
| LM75-10C051515-23 | 72 | 90~264VAC/120~373VDC | 5V/6A,15V/2.3A,-15V/0.5A | -30℃ to +70℃ | 3 | 82 | 3000 |
-
|
|
|
| LM75-23B12 | 72 | 85~305VAC/120~430VDC | 12V/6A | -30℃ to +70℃ | 1 | 87 | 4000 |
-
|
|
|
| LM75-10C052412-15 | 73 | 90~264VAC/120~373VDC | 5V/5A,24V/1.5A,12V/1A | -30℃ to +70℃ | 3 | 84 | 3000 |
-
|
|
|
| LM75-10D0524-20 | 73 | 90~264VAC/120~373VDC | 5V/5A,24V/2A | -30℃ to +70℃ | 2 | 84 | 3000 |
-
|
|
|
| LI75-20B12R2 | 75 | 90~264 | - | - | 1 | - | 4000 |
-
|
|
|
| LI75-20B24R2 | 75 | 90~264 | - | - | 1 | - | 4000 |
-
|
|
|
| LI75-20B48R2 | 75 | 90~264 | - | - | 1 | - | 4000 |
-
|
|
|
| LM75-20B15 | 75 | 85~264VAC/120~373VDC | 15V/5A | -30℃ to +70℃ | 1 | 88 | 4000 |
-
|
|
|
| LM75-22B15 | 75 | 165~264VAC/200~373VDC | 15V/5A | -30℃ to +70℃ | 1 | 88 | 4000 |
-
|
|
|
| LMF75-20B05 | 75 | 85~264VAC/120~370VDC | 5V/15A | -25℃ to +70℃ | 1 | 82 | 4000 |
-
|
|
|
| LMF75-20B15 | 75 | 85~264VAC/120~370VDC | 15V/5A | -25℃ to +70℃ | 1 | 86 | 4000 |
-
|
|
|
| LM75-23B15 | 75 | 85~305VAC/120~430VDC | 12V/6A | -30℃ to +70℃ | 1 | 87 | 4000 |
-
|
|
|
| LMF75-20B12 | 75.6 | 85~264VAC/120~370VDC | 12V/6.3A | -25℃ to +70℃ | 1 | 85 | 4000 |
-
|
|
|
| LM75-23B36 | 75.6 | 85~305VAC/120~430VDC | 36V/2.1A | -30℃ to +70℃ | 1 | 90 | 4000 |
-
|
|
|
| LM75-20B36 | 75.6 | 85~264VAC/120~373VDC | 36V/2.1A | -30℃ to +70℃ | 1 | 90 | 4000 |
-
|
|
|
| LM75-22B36 | 75.6 | 165~264VAC/200~373VDC | 36V/2.1A | -30℃ to +70℃ | 1 | 90 | 4000 |
-
|
|
|
| LM75-20B24 | 76.8 | 85~264VAC/120~373VDC | 24V/3.2A | -30℃ to +70℃ | 1 | 90 | 4000 |
-
|
|
|
| LM75-20B48 | 76.8 | 85~264VAC/120~373VDC | 48V/1.6A | -30℃ to +70℃ | 1 | 91.5 | 4000 |
-
|
|
|
| LM75-22B24 | 76.8 | 165~264VAC/200~373VDC | 24V/3.2A | -30℃ to +70℃ | 1 | 90 | 4000 |
-
|
|
|
| LM75-22B48 | 76.8 | 165~264VAC/200~373VDC | 48V/1.6A | -30℃ to +70℃ | 1 | 91.5 | 4000 |
-
|
|
|
| LMF75-20B24 | 76.8 | 85~264VAC/120~370VDC | 24V/3.2A | -25℃ to +70℃ | 1 | 87 | 4000 |
-
|
|
|
| LMF75-20B48 | 76.8 | 85~264VAC/120~370VDC | 48V/1.6A | -25℃ to +70℃ | 1 | 89 | 4000 |
-
|
|
|
| LM75-23B24 | 76.8 | 85~305VAC/120~430VDC | 24V/3.2A | -30℃ to +70℃ | 1 | 89 | 4000 |
-
|
|
|
| LM75-23B48 | 76.8 | 85~305VAC/120~430VDC | 48V/1.6A | -30℃ to +70℃ | 1 | 90.5 | 4000 |
-
|
|
|
| LI100-20B12PR2 | 90 | 85~264 | - | - | 1 | - | 4000 |
-
|
|
|
| LM100-23B05 | 90 | 85~305VAC/120~431VDC | 5V/18A | -30℃ to +70℃ | 1 | 85.5 | 4000 |
-
|
|
|
| LM100-20B05 | 90 | 85~264VAC/120~373VDC | 5V/18A | -30℃ to +70℃ | 1 | 86 | 4000 |
-
|
|
|
| LM100-22B05 | 90 | 165~264VAC/200~373VDC | 5V/18A | -30℃ to +70℃ | 1 | 86 | 4000 |
-
|
|
|
| LM100-10C051212-35 | 94 | 90~264VAC/120~373VDC | 5V/8A,12V/3.5A,-12V/1A | -30℃ to +70℃ | 3 | 84 | 3000 |
-
|
|
|
| LM100-10C051515-30 | 95 | 90~264VAC/120~373VDC | 5V/7A,15V/3A,-15V/1A | -30℃ to +70℃ | 3 | 85 | 3000 |
-
|
|
|
| LM100-10C052412-20 | 96 | 90~264VAC/120~373VDC | 5V/6A,24V/2A,12V/1.5A | -30℃ to +70℃ | 3 | 85 | 3000 |
-
|
|
|
| LM100-10D1224-20 | 96 | 90~264VAC/120~373VDC | 12V/4A,24V/2A | -30℃ to +70℃ | 2 | 87 | 3000 |
-
|
|
|
| LM100-10D0524-30 | 97 | 90~264VAC/120~373VDC | 5V/5A,24V/3A | -30℃ to +70℃ | 2 | 85 | 3000 |
-
|
|
|
| LI100-20B15PR2 | 97.5 | 85~264 | - | - | 1 | - | 4000 |
-
|
|
|
| LMF100-23B15 | 100.5 | 85 - 305VAC/120 - 430VDC | 15V/6.7A | -30℃ to +70℃ | 1 | 86 | 4000 | - |
|
|
| LI100-20B24PR2 | 100.8 | 85~264 | - | - | 1 | - | 4000 |
-
|
|
|
| LI100-20B48PR2 | 100.8 | 85~264 | - | - | 1 | - | 4000 |
-
|
|
|
| LM100-23B36 | 100.8 | 85~305VAC/120~431VDC | 36V/2.8A | -30℃ to +70℃ | 1 | 89.5 | 4000 |
-
|
|
|
| LMF100-23B24 | 100.8 | 85 - 305VAC/120 - 430VDC | 24V/4.2A | -30℃ to +70℃ | 1 | 86 | 4000 | - |
|
|
| LMF100-23B48 | 100.8 | 85 - 305VAC/120 - 430VDC | 48V/2.1A | -30℃ to +70℃ | 1 | 87 | 4000 | - |
|
|
| LM100-20B36 | 100.8 | 85~264VAC/120~373VDC | 36V/2.8A | -30℃ to +70℃ | 1 | 90 | 4000 |
-
|
|
|
| LM100-22B36 | 100.8 | 165~264VAC/200~373VDC | 36V/2.8A | -30℃ to +70℃ | 1 | 90 | 4000 |
-
|
|
|
| LM100-23B12 | 102 | 85~305VAC/120~431VDC | 12V/8.5A | -30℃ to +70℃ | 1 | 87 | 4000 |
-
|
|
|
| LMF100-23B12 | 102 | 85 - 305VAC/120 - 430VDC | 12V/8.5A | -30℃ to +70℃ | 1 | 85 | 4000 | - |
|
|
| LM100-20B12 | 102 | 85~264VAC/120~373VDC | 12V/8.5A | -30℃ to +70℃ | 1 | 87.5 | 4000 |
-
|
|
|
| LM100-22B12 | 102 | 165~264VAC/200~373VDC | 12V/8.5A | -30℃ to +70℃ | 1 | 87.5 | 4000 |
-
|
|
|
| LM100-23B15 | 105 | 85~305VAC/120~431VDC | 15V/7.0A | -30℃ to +70℃ | 1 | 87 | 4000 |
-
|
|
|
| LM100-20B15 | 105 | 85~264VAC/120~373VDC | 15V/7A | -30℃ to +70℃ | 1 | 87.5 | 4000 |
-
|
|
|
| LM100-22B15 | 105 | 165~264VAC/200~373VDC | 15V/7A | -30℃ to +70℃ | 1 | 87.5 | 4000 |
-
|
|
|
| LM100-23B24 | 108 | 85~305VAC/120~431VDC | 24V/4.5A | -30℃ to +70℃ | 1 | 89.5 | 4000 |
-
|
|
|
| LM100-20B24 | 108 | 85~264VAC/120~373VDC | 24V/4.5A | -30℃ to +70℃ | 1 | 90 | 4000 |
-
|
|
|
| LM100-22B24 | 108 | 165~264VAC/200~373VDC | 24V/4.5A | -30℃ to +70℃ | 1 | 90 | 4000 |
-
|
|
|
| LM100-23B48 | 110.4 | 85~305VAC/120~431VDC | 48V/2.3A | -30℃ to +70℃ | 1 | 90.5 | 4000 |
-
|
|
|
| LM100-20B48 | 110.4 | 85~264VAC/120~373VDC | 48V/2.3A | -30℃ to +70℃ | 1 | 91 | 4000 |
-
|
|
|
| LM100-22B48 | 110.4 | 165~264VAC/200~373VDC | 48V/2.3A | -30℃ to +70℃ | 1 | 91 | 4000 |
-
|
|
|
| LOF120-20B12-C | 114 | 85~264 | - | -40℃ to +85℃ | - | 94 | 4000 | - |
|
|
| LOF120-20B15-C | 114 | 85~264 | - | -40℃ to +85℃ | - | 94 | 4000 | - |
|
|
| LOF120-20B27-C | 119.9 | 85~264 | - | -40℃ to +85℃ | - | 95 | 4000 | - |
|
|
| LI120-20B12R2S | 120 | 90~264 | - | - | 1 | - | 4000 | - |
|
|
| LI120-20B24R2S | 120 | 90~264 | - | - | 1 | - | 4000 | - |
|
|
| LI120-20B48R2S | 120 | 90~264 | - | - | 1 | - | 4000 | - |
|
|
| LI120-13B12 | 120 | 85~305 | - | - | 1 | - | 3000 | - |
|
|
| LI120-13B24 | 120 | 85~305 | - | - | 1 | - | 3000 | - |
|
|
| LI120-20B12R2 | 120 | 90~264 | - | - | 1 | - | 4000 |
-
|
|
|
| LI120-20B24R2 | 120 | 90~264 | - | - | 1 | - | 4000 |
-
|
|
|
| LI120-20B48R2 | 120 | 90~264 | - | - | 1 | - | 4000 |
-
|
|
|
| LOF120-20B12 | 120 | 85~264 | - | -40℃ to +85℃ | - | 94 | 4000 | - |
|
|
| LOF120-20B15 | 120 | 85~264 | - | -40℃ to +85℃ | - | 94 | 4000 | - |
|
|
| LOF120-20B24 | 120 | 85~264 | - | -40℃ to +85℃ | - | 95 | 4000 | - |
|
|
| LOF120-20B27 | 120 | 85~264 | - | -40℃ to +85℃ | - | 95 | 4000 | - |
|
|
| LOF120-20B48 | 120 | 85~264 | - | -40℃ to +85℃ | - | 94.5 | 4000 | - |
|
|
| LOF120-20B24-C | 120 | 85~264 | - | -40℃ to +85℃ | - | 95 | 4000 | - |
|
|
| LOF120-20B48-C | 120 | 85~264 | - | -40℃ to +85℃ | - | 94.5 | 4000 | - |
|
|
| LM200-10B05 | 150 | 90~132VAC/180~264VAC/240~373VDC | 5V/30A | -30℃ to +70℃ | 1 | 87 | 3000 |
-
|
|
|
| LI150-13B29 | 150 | 85~305 | - | - | 1 | - | 3000 | - |
|
|
| LM150-20B12 | 150 | 85~264VAC/120~373VDC | 12V/12.5A | -30℃ to +70℃ | 1 | 86 | 4000 |
-
|
|
|
| LM150-20B15 | 150 | 85~264VAC/120~373VDC | 15V/10A | -30℃ to +70℃ | 1 | 87 | 4000 |
-
|
|
|
| LM150-22B12 | 150 | 165~264VAC/180~373VDC | 12V/12.5A | -30℃ to +70℃ | 1 | 86 | 4000 |
-
|
|
|
| LM150-22B15 | 150 | 165~264VAC/180~373VDC | 15V/10A | -30℃ to +70℃ | 1 | 87 | 4000 |
-
|
|
|
| LM150-23B12 | 150 | 85~305VAC/120~431VDC | 12V/12.5A | -30℃ to +70℃ | 1 | 86 | 4000 |
-
|
|
|
| LM150-23B15 | 150 | 85~305VAC/120~431VDC | 15V/10A | -30℃ to +70℃ | 1 | 87 | 4000 |
-
|
|
|
| LM150-12M1224 | 150 | 180~264VAC/240~370VDC | 12V/12.5A | -30℃ to +70℃ | 1 | 84 | 3000 | - |
|
|
| LMF150-23B12 | 150 | 85 - 305VAC/120 - 430VDC | 12V/12.5A | -30℃ to +70℃ | 1 | 85.5 | 4000 | - |
|
|
| LMF150-23B15 | 150 | 85 - 305VAC/120 - 430VDC | 15V/10A | -30℃ to +70℃ | 1 | 86 | 4000 | - |
|
|
| LMF150-23B24 | 151.2 | 85 - 305VAC/120 - 430VDC | 24V/6.3A | -30℃ to +70℃ | 1 | 87 | 4000 | - |
|
|
| LMF150-23B48 | 153.6 | 85 - 305VAC/120 - 430VDC | 48V/3.2A | -30℃ to +70℃ | 1 | 88 | 4000 | - |
|
|
| LM150-20B36 | 154.8 | 85~264VAC/120~373VDC | 36V/4.3A | -30℃ to +70℃ | 1 | 88 | 4000 |
-
|
|
|
| LM150-22B36 | 154.8 | 165~264VAC/180~373VDC | 36V/4.3A | -30℃ to +70℃ | 1 | 88 | 4000 |
-
|
|
|
| LM150-23B36 | 154.8 | 85~305VAC/120~431VDC | 36V/4.3A | -30℃ to +70℃ | 1 | 88 | 4000 |
-
|
|
|
| LM150-20B24 | 156 | 85~264VAC/120~373VDC | 24V/6.5A | -30℃ to +70℃ | 1 | 88 | 4000 |
-
|
|
|
| LM150-22B24 | 156 | 165~264VAC/180~373VDC | 24V/6.5A | -30℃ to +70℃ | 1 | 88 | 4000 |
-
|
|
|
| LM150-23B24 | 156 | 85~305VAC/120~431VDC | 24V/6.5A | -30℃ to +70℃ | 1 | 88 | 4000 |
-
|
|
|
| LM150-20B48 | 158.4 | 85~264VAC/120~373VDC | 48V/3.3A | -30℃ to +70℃ | 1 | 89 | 4000 |
-
|
|
|
| LM150-22B48 | 158.4 | 165~264VAC/180~373VDC | 48V/3.3A | -30℃ to +70℃ | 1 | 89 | 4000 |
-
|
|
|
| LM150-23B48 | 158.4 | 85~305VAC/120~431VDC | 48V/3.3A | -30℃ to +70℃ | 1 | 89 | 4000 |
-
|
|
|
| LM200-12B05 | 200 | 176~264VAC/240~373VDC | 5V/40A | -30℃ to +70℃ | 1 | 87 | 3000 |
-
|
|
|
| LMF200-23B05 | 200 | 85~305VAC/120~430VDC | 5V/40A | -30℃ to +70℃ | 1 | 85 | 4000 | - |
|
|
| LMF200-23B12 | 200.4 | 85~305VAC/120~430VDC | 12V/16.7A | -30℃ to +70℃ | 1 | 88 | 4000 | - |
|
|
| LMF200-23B15 | 201 | 85~305VAC/120~430VDC | 15V/13.4A | -30℃ to +70℃ | 1 | 88 | 4000 | - |
|
|
| LMF200-23B24 | 201.6 | 85~305VAC/120~430VDC | 24V/8.4A | -30℃ to +70℃ | 1 | 88 | 4000 | - |
|
|
| LMF200-23B48 | 201.6 | 85~305VAC/120~430VDC | 48V/4.2A | -30℃ to +70℃ | 1 | 88 | 4000 | - |
|
|
| LM200-10B12 | 204 | 90~132VAC/180~264VAC/240~373VDC | 12V/17A | -30℃ to +70℃ | 1 | 87.5 | 3000 |
-
|
|
|
| LM200-12B12 | 204 | 176~264VAC/240~373VDC | 12V/17A | -30℃ to +70℃ | 1 | 87.5 | 3000 |
-
|
|
|
| LM200-10B15 | 210 | 90~132VAC/180~264VAC/240~373VDC | 15V/14A | -30℃ to +70℃ | 1 | 88 | 3000 |
-
|
|
|
| LM200-12B15 | 210 | 176~264VAC/240~373VDC | 15V/14A | -30℃ to +70℃ | 1 | 88 | 3000 |
-
|
|
|
| LM200-10B24 | 211.2 | 90~132VAC/180~264VAC/240~373VDC | 24V/8.8A | -30℃ to +70℃ | 1 | 88.5 | 3000 |
-
|
|
|
| LM200-10B48 | 211.2 | 90~132VAC/180~264VAC/240~373VDC | 48V/4.4A | -30℃ to +70℃ | 1 | 89.5 | 3000 |
-
|
|
|
| LM200-12B24 | 211.2 | 176~264VAC/240~373VDC | 24V/8.8A | -30℃ to +70℃ | 1 | 88.5 | 3000 |
-
|
|
|
| LM200-12B48 | 211.2 | 176~264VAC/240~373VDC | 48V/4.4A | -30℃ to +70℃ | 1 | 89.5 | 3000 |
-
|
|
|
| LM200-10B36 | 212.4 | 90~132VAC/180~264VAC/240~373VDC | 36V/5.9A | -30℃ to +70℃ | 1 | 89 | 3000 |
-
|
|
|
| LM200-12B36 | 212.4 | 176~264VAC/240~373VDC | 36V/5.9A | -30℃ to +70℃ | 1 | 89 | 3000 |
-
|
|
|
| LOF225-20B12 | 225 | 85~264 | - | -40℃ to +70℃ | - | 93 | 4000 | - |
|
|
| LOF225-20B15 | 225 | 85~264 | - | -40℃ to +70℃ | - | 93 | 4000 | - |
|
|
| LOF225-20B24 | 225 | 85~264 | - | -40℃ to +70℃ | - | 94 | 4000 | - |
|
|
| LOF225-20B27 | 225 | 85~264 | - | -40℃ to +70℃ | - | 94 | 4000 | - |
|
|
| LOF225-20B48 | 225 | 85~264 | - | -40℃ to +70℃ | - | 94 | 4000 | - |
|
|
| LOF225-20B12-C | 225 | 85~264 | - | -40℃ to +70℃ | - | 93 | 4000 | - |
|
|
| LOF225-20B15-C | 225 | 85~264 | - | -40℃ to +70℃ | - | 93 | 4000 | - |
|
|
| LOF225-20B24-C | 225 | 85~264 | - | -40℃ to +70℃ | - | 94 | 4000 | - |
|
|
| LOF225-20B27-C | 225 | 85~264 | - | -40℃ to +70℃ | - | 94 | 4000 | - |
|
|
| LOF225-20B48-C | 225 | 85~264 | - | -40℃ to +70℃ | - | 94 | 4000 | - |
|
|
| LMF320-23B05 | 300 | 85~305VAC/120~430VDC | 5V/60A | -30℃ to +70℃ | 1 | 84 | 4000 | - |
|
|
| LOF350-20B12-C | 300 | 90~264 | - | -40℃ to +70℃ | - | 92 | 4000 | - |
|
|
| LM350-10B05 | 300 | 90~132VAC/180~264VAC/240~373VDC | 5V/60A | -30℃ to +70℃ | 1 | 83.5 | 3000 |
-
|
|
|
| LMF320-23B12 | 320.4 | 85~305VAC/120~430VDC | 12V/26.7A | -30℃ to +70℃ | 1 | 86.5 | 4000 | - |
|
|
| LMF320-23B15 | 321 | 85~305VAC/120~430VDC | 15V/21.4A | -30℃ to +70℃ | 1 | 89 | 4000 | - |
|
|
| LMF320-23B24 | 321.6 | 85~305VAC/120~430VDC | 24V/13.4A | -30℃ to +70℃ | 1 | 88.5 | 4000 | - |
|
|
| LMF320-23B48 | 321.6 | 85~305VAC/120~430VDC | 48V/6.7A | -30℃ to +70℃ | 1 | 89 | 4000 | - |
|
|
| LOF350-20B15-C | 325 | 90~264 | - | -40℃ to +70℃ | - | 92 | 4000 | - |
|
|
| LM350-10B12 | 348 | 90~132VAC/180~264VAC/240~373VDC | 12V/29A | -30℃ to +70℃ | 1 | 85 | 3000 |
-
|
|
|
| LM350-10B15 | 348 | 90~132VAC/180~264VAC/240~373VDC | 15V/23.2A | -30℃ to +70℃ | 1 | 86 | 3000 |
-
|
|
|
| LM350-12B12 | 348 | 176~264VAC/240~373VDC | 12V/29A | -30℃ to +70℃ | 1 | 85.5 | 3000 |
-
|
|
|
| LM350-12B15 | 348 | 176~264VAC/240~373VDC | 15V/23.2A | -30℃ to +70℃ | 1 | 87.5 | 3000 |
-
|
|
|
| LM350-10B36 | 349.2 | 90~132VAC/180~264VAC/240~373VDC | 36V/9.7A | -30℃ to +70℃ | 1 | 88 | 3000 |
-
|
|
|
| LM350-12B36 | 349.2 | 176~264VAC/240~373VDC | 36V/9.7A | -30℃ to +70℃ | 1 | 88 | 3000 |
-
|
|
|
| LOF350-20B12 | 350 | 90~264 | - | -40℃ to +70℃ | - | 92 | 4000 | - |
|
|
| LOF350-20B15 | 350 | 90~264 | - | -40℃ to +70℃ | - | 92 | 4000 | - |
|
|
| LOF350-20B24 | 350 | 90~264 | - | -40℃ to +70℃ | - | 93 | 4000 | - |
|
|
| LOF350-20B27 | 350 | 90~264 | - | -40℃ to +70℃ | - | 93 | 4000 | - |
|
|
| LOF350-20B48 | 350 | 90~264 | - | -40℃ to +70℃ | - | 94 | 4000 | - |
|
|
| LM350-12B05 | 350 | 176~264VAC/240~373VDC | 5V/60A | -30℃ to +70℃ | 1 | 84 | 3000 |
-
|
|
|
| LOF350-20B24-C | 350.4 | 90~264 | - | -40℃ to +70℃ | - | 93 | 4000 | - |
|
|
| LOF350-20B48-C | 350.4 | 90~264 | - | -40℃ to +70℃ | - | 94 | 4000 | - |
|
|
| LM350-10B24 | 350.4 | 90~132VAC/180~264VAC/240~373VDC | 24V/14.6A | -30℃ to +70℃ | 1 | 87 | 3000 |
-
|
|
|
| LM350-10B48 | 350.4 | 90~132VAC/180~264VAC/240~373VDC | 48V/7.3A | -30℃ to +70℃ | 1 | 88.5 | 3000 |
-
|
|
|
| LM350-12B24 | 350.4 | 176~264VAC/240~373VDC | 24V/14.6A | -30℃ to +70℃ | 1 | 87 | 3000 |
-
|
|
|
| LM350-12B48 | 350.4 | 176~264VAC/240~373VDC | 48V/7.3A | -30℃ to +70℃ | 1 | 89 | 3000 |
-
|
|
|
| LOF350-20B27-C | 351 | 90~264 | - | -40℃ to +70℃ | - | 93 | 4000 | - |
|
|
| LM450-12B12 | 450 | 176~264VAC/240~373VDC | 12V/37.5A | -30℃ to +70℃ | 1 | 88 | 3000 | - |
|
|
| LM450-12B15 | 450 | 176~264VAC/240~373VDC | 15V/30A | -30℃ to +70℃ | 1 | 88 | 3000 | - |
|
|
| LM450-12B24 | 451.2 | 176~264VAC/240~373VDC | 24V/18.8A | -30℃ to +70℃ | 1 | 88 | 3000 | - |
|
|
| LM450-12B48 | 451.2 | 176~264VAC/240~373VDC | 48V/9.4A | -30℃ to +70℃ | 1 | 88 | 3000 | - |
|
|
| LM600-12B36 | 597.6 | 176~264VAC/240~373VDC | 36V/16.6A | -30℃ to +60℃ | 1 | 87 | 3000 |
-
|
|
|
| LM600-12B27 | 599.4 | 76~264VAC/240~373VDC | 27V/22.2A | -30℃ to +60℃ | 1 | 87 | 3000 |
-
|
|
|
| LM600-12B12 | 600 | 176~264VAC/240~373VDC | 12V/50A | -30℃ to +60℃ | 1 | 85 | 3000 |
-
|
|
|
| LM600-12B15 | 600 | 176~264VAC/240~373VDC | 15V/40A | -30℃ to +60℃ | 1 | 86 | 3000 |
-
|
|
|
| LM600-12B24 | 600 | 176~264VAC/240~373VDC | 24V/25A | -30℃ to +60℃ | 1 | 87 | 3000 |
-
|
|
|
| LM600-12B48 | 600 | 176~264VAC/240~373VDC | 48V/12.5A | -30℃ to +60℃ | 1 | 88 | 3000 |
-
|
|
|
* For reference only. The detailed info please refer to the datasheet.
| Product No. |
| LM15-23B03 |
| LI30-20B05PR2 |
| LM15-23B05 |
| LM15-23B15 |
| LM15-23B24 |
| LM15-23B48 |
| LM15-23B12 |
| LM25-23B03 |
| LI30-20B12PR2 |
| LM25-23B05 |
| LM25-23B12 |
| LM25-23B15 |
| LM25-23B24 |
| LM25-23B48 |
| LM30-00J0512-03E |
| LI30-20B15PR2 |
| LM35-10D0512-10 |
| LI60-20B05PR2 |
| LM35-10C051212-10 |
| LM35-20B05 |
| LM35-22B05 |
| LM35-10C051515-10 |
| LM35-10D0524-10 |
| LM35-23B05 |
| LM35-20B12 |
| LM35-20B15 |
| LM35-20B24 |
| LM35-22B12 |
| LM35-22B15 |
| LM35-22B24 |
| LI30-20B24PR2 |
| LI30-20B48PR2 |
| LM35-22B12-DX |
| LM35-23B12 |
| LM35-23B15 |
| LM35-23B24 |
| LM35-10C052412-05 |
| LM50-22B05 |
| LM50-20B05 |
| LM50-10C051212-20 |
| LM50-10C051515-15 |
| LM50-23B05 |
| LM50-22B12 |
| LM50-20B12 |
| LM50-10A12 |
| LM50-23B12 |
| LM50-22B15 |
| LM50-20B15 |
| LM50-10C052412-10 |
| LM50-23B15 |
| LM50-23B36 |
| LM50-22B36 |
| LM50-20B36 |
| LM50-22B24 |
| LM50-20B24 |
| LM50-23B24 |
| LM50-23B48 |
| LM50-22B48 |
| LM50-20B48 |
| LM50-10D0524-14 |
| LI60-20B12PR2 |
| LM50-10D0512-20 |
| LI60-20B15PR2 |
| LI60-20B24PR2 |
| LI60-20B48PR2 |
| LM75-10C051212-28 |
| LM75-20B05 |
| LM75-22B05 |
| LM75-23B05 |
| LM75-10D0512-30 |
| LM75-20B12 |
| LM75-22B12 |
| LM75-10C051515-23 |
| LM75-23B12 |
| LM75-10C052412-15 |
| LM75-10D0524-20 |
| LI75-20B12R2 |
| LI75-20B24R2 |
| LI75-20B48R2 |
| LM75-20B15 |
| LM75-22B15 |
| LMF75-20B05 |
| LMF75-20B15 |
| LM75-23B15 |
| LMF75-20B12 |
| LM75-23B36 |
| LM75-20B36 |
| LM75-22B36 |
| LM75-20B24 |
| LM75-20B48 |
| LM75-22B24 |
| LM75-22B48 |
| LMF75-20B24 |
| LMF75-20B48 |
| LM75-23B24 |
| LM75-23B48 |
| LI100-20B12PR2 |
| LM100-23B05 |
| LM100-20B05 |
| LM100-22B05 |
| LM100-10C051212-35 |
| LM100-10C051515-30 |
| LM100-10C052412-20 |
| LM100-10D1224-20 |
| LM100-10D0524-30 |
| LI100-20B15PR2 |
| LMF100-23B15 |
| LI100-20B24PR2 |
| LI100-20B48PR2 |
| LM100-23B36 |
| LMF100-23B24 |
| LMF100-23B48 |
| LM100-20B36 |
| LM100-22B36 |
| LM100-23B12 |
| LMF100-23B12 |
| LM100-20B12 |
| LM100-22B12 |
| LM100-23B15 |
| LM100-20B15 |
| LM100-22B15 |
| LM100-23B24 |
| LM100-20B24 |
| LM100-22B24 |
| LM100-23B48 |
| LM100-20B48 |
| LM100-22B48 |
| LOF120-20B12-C |
| LOF120-20B15-C |
| LOF120-20B27-C |
| LI120-20B12R2S |
| LI120-20B24R2S |
| LI120-20B48R2S |
| LI120-13B12 |
| LI120-13B24 |
| LI120-20B12R2 |
| LI120-20B24R2 |
| LI120-20B48R2 |
| LOF120-20B12 |
| LOF120-20B15 |
| LOF120-20B24 |
| LOF120-20B27 |
| LOF120-20B48 |
| LOF120-20B24-C |
| LOF120-20B48-C |
| LM200-10B05 |
| LI150-13B29 |
| LM150-20B12 |
| LM150-20B15 |
| LM150-22B12 |
| LM150-22B15 |
| LM150-23B12 |
| LM150-23B15 |
| LM150-12M1224 |
| LMF150-23B12 |
| LMF150-23B15 |
| LMF150-23B24 |
| LMF150-23B48 |
| LM150-20B36 |
| LM150-22B36 |
| LM150-23B36 |
| LM150-20B24 |
| LM150-22B24 |
| LM150-23B24 |
| LM150-20B48 |
| LM150-22B48 |
| LM150-23B48 |
| LM200-12B05 |
| LMF200-23B05 |
| LMF200-23B12 |
| LMF200-23B15 |
| LMF200-23B24 |
| LMF200-23B48 |
| LM200-10B12 |
| LM200-12B12 |
| LM200-10B15 |
| LM200-12B15 |
| LM200-10B24 |
| LM200-10B48 |
| LM200-12B24 |
| LM200-12B48 |
| LM200-10B36 |
| LM200-12B36 |
| LOF225-20B12 |
| LOF225-20B15 |
| LOF225-20B24 |
| LOF225-20B27 |
| LOF225-20B48 |
| LOF225-20B12-C |
| LOF225-20B15-C |
| LOF225-20B24-C |
| LOF225-20B27-C |
| LOF225-20B48-C |
| LMF320-23B05 |
| LOF350-20B12-C |
| LM350-10B05 |
| LMF320-23B12 |
| LMF320-23B15 |
| LMF320-23B24 |
| LMF320-23B48 |
| LOF350-20B15-C |
| LM350-10B12 |
| LM350-10B15 |
| LM350-12B12 |
| LM350-12B15 |
| LM350-10B36 |
| LM350-12B36 |
| LOF350-20B12 |
| LOF350-20B15 |
| LOF350-20B24 |
| LOF350-20B27 |
| LOF350-20B48 |
| LM350-12B05 |
| LOF350-20B24-C |
| LOF350-20B48-C |
| LM350-10B24 |
| LM350-10B48 |
| LM350-12B24 |
| LM350-12B48 |
| LOF350-20B27-C |
| LM450-12B12 |
| LM450-12B15 |
| LM450-12B24 |
| LM450-12B48 |
| LM600-12B36 |
| LM600-12B27 |
| LM600-12B12 |
| LM600-12B15 |
| LM600-12B24 |
| LM600-12B48 |
