● Fitted devices: 1. NAMUR Sensors;2. Mechanical Joints.
● Phase-angel and inverse control setting;
● Open circuit detection setting
● Respective Isolation(2,500VDC between
Input/Output/Power source);
● Operation Temperature:-20℃-+60℃
● Reliable Performance (MTBF>1,000,000 Hours).

● High efficiency up to 88%
● 2:1 Wide Input Voltage Range
● 1.5KVDC Input/Output Isolation
● Six-sided Metal Shield
● Short Circuit Protection(automatic
recovery)
● Operating Temperature: -40°C to +85°C
● Internal SMD construction
● Industry Standard Pin out
● MTBF>1,000,000 hours
● RoHS Compliance

Small Footprint, Very thin package
3KVDC Isolation
Temperature Range: -40°C to +85°C
No Heat sink Required
High Power Density
No External Component Required
Industry Standard Pinout
Pin-out compatible with DCP01 Series
Short circuit protection
RoHS Compliance
