Compact and All-round AC/DC Converter LS-R3 Series

Mornsun compact size AC DC converter LS-R3.jpg



The flyback converter in the switching power supply is the most common AC/DC power supply. With the development of integrated circuit technology, most of the circuits in the flyback converter are integrated into the IC, and there are few peripheral components. That makes it possible to build a power supply that has general functions with just adding a suitable transformer. It’s simple but not optimized for personalized and differentiated needs, engineers are always puzzled to balance the design cycle, cost, reliability, ease of use, dimensions, performance, and personalization of power supply. And now, MORNSUN's newest AC/DC Converter "LS-R3" series can resolve this puzzlement.



MORNSUN's newest AC/DC Converter LS-R3.jpg


Save Cost from Multi-dimension

The cost of the power supply section accounts for a large proportion of the cost of electronic devices, forcing many customers to use discrete solutions to reduce costs. But discrete solutions can only reduce raw material cost, there’re still multiple types of cost included such as design cost, manufacturing cost, time cost, management cost, quality cost, and invisible risk cost, etc.


MORNUSN LS-R3 series save your cost from Multi-dimension


Design cost: MORNSUN integrates circuit into its self-designed IC which further simplifies the peripheral circuits of the AC/DC Converter LS-R3 series. thereby the number of peripheral components is maximally reduced to save cost.


Manufacturing cost: LS-R3 series is full automation manufacturing. It not only reduces the labor costs but also improves product consistency and pass rate, which makes LS-R3 series provide the most competitive price to customers with low-quality cost and manufacturing cost.


Time cost: We have countless power supply applications and one-to-one support services from FAE to help customers design peripheral circuits according to their own applications, which can shorten product design cycles, save customer’s design costs and time.


Flexible Peripheral Design for a Wide Range of Application

Engineers expect to make a personalized product to meet different electronic devices in the shortest design circle. However, shortening the design time often results in rough product design, and pursuing personalization may make the design complicated with poor compatibility and low economical efficiency.


MORNSUN LS-R3 series shoot customer's troubles with the all-matching core design with a flexible peripheral circuit.


By adopting different peripheral circuits, LS-R3 can be used in almost all applications including low-cost consumer products and even high-end power for the extremely harsh outdoor environments.


MORNSUN AC DC CONVETERF Flexible Peripheral Design for All-rounder Application.jpg

MORNSUN AC DC CONVETERF Flexible Peripheral Design for All-rounder Application.jpg


Compact Size for Miniaturization Trend


In order to conform to the trend of miniaturization and meet the application requirement of customer in smaller dimensions, the LS-R3 series removes all redundant designs, compacts the circuit layout, replaces the terminals, and design the transformer according to the power section. So the dimensions (26.4x14.73x11mm) are decreased by about 43%.


High Reliability Controlled by Reliable Platform


The circuit of the flyback converter in the power supply product is simple and easy to be designed and produced, engineers maybe generally not taken seriously to its potential reliability risk. But according to statistical data, it states that most of the cause of failure in electronic devices is the damage of the power supply. Therefore, the power supply is the "key" of the entire system's reliability.


As the below picture showed, the high reliability of MORNSUN LS-R3 series is guaranteed by our reliability platforms. At the same time, massive customer application cases have provided us with countless references input to further optimize our reliability platform, and to ensure our product reliability.

MORNUSN RELIABLE PLATFORMS ENSURE QUALITY.jpg


Outstanding Performance to Improve Product Competitiveness


The LS-R3 series has achieved a wide input voltage range of 85-305VAC, which can meet the global universal voltage requirements; the static power consumption is as low as 0.1W, which meets the six-level energy efficiency and is suitable for many industries with high power consumption requirements; it can work with a full load at -40℃ ultra-low temperature environment, and 50% load at +85℃ high temperature. And it can be compatible with various applications.


MORNSUN AC DC CONVERTER IN SMART HOME NEW ENERGY.jpg


Features of AC/DC Converter LS-R3 Series


● Compact size:26.4x14.73x11mm(5W)

● Wide input range:85-305VAC,accepting AC or DC input

● Operating temperature range: -40℃ to +85℃

● Multi-application, flexible layout

● High power density, high reliability

● No-load power consumption as low as 0.1W

● Output short circuit, over-current protection

● Meet IEC/EN/UL62368 standards (pending)




* For detailed information please refer to the related datasheet, product news is for reference only.
Please refer to the technical manual for specific product parameters:

Series Power(W) Vin(VAC) Vin(VDC) Vout(VDC) Iout No. of Outputs Isolation Package Dimension(mm) Footprint & 3D Markings Datasheet Sample Buy
LS03-13B03R3 1.98 85-305 70-430 3.3 600mA 1 3000VAC SIP 26.40*12.58*11.00
LS03-13B05R3 3 85-305 70-430 5 600mA 1 3000VAC SIP 26.40*12.58*11.00
LS03-13B09R3 3 85-305 70-430 9 333mA 1 3000VAC SIP 26.40*12.58*11.00
LS03-13B12R3 3 85-305 70-430 12 250mA 1 3000VAC SIP 26.40*12.58*11.00
LS03-13B15R3 3 85-305 70-430 15 200mA 1 3000VAC SIP 26.40*12.58*11.00
LS03-13B24R3 3 85-305 70-430 24 125mA 1 3000VAC SIP 26.40*12.58*11.00
LS05-13B03R3 3.3 85-305 70-430 3.3 1000mA 1 3600VAC SIP 26.40*14.73*11.00
LS05-13B03R3-F 3.3 85-305 70-430 3.3 1000mA 1 3600VAC SIP 27.84*11.60*17.60
LS05-13B05R3 5 85-305 70-430 5 1000mA 1 3600VAC SIP 26.40*14.73*11.00
LS05-13B05R3-F 5 85-305 70-430 5 1000mA 1 3600VAC SIP 27.84*11.60*17.60
LS05-13B09R3 5 85-305 70-430 9 560mA 1 3600VAC SIP 26.40*14.73*11.00
LS05-13B09R3-F 5 85-305 70-430 9 560mA 1 3600VAC SIP 27.84*11.60*17.60
LS05-13B12R3 5 85-305 70-430 12 420mA 1 3600VAC SIP 26.40*14.73*11.00
LS05-13B12R3-F 5 85-305 70-430 12 420mA 1 3600VAC SIP 27.84*11.60*17.60
LS05-13B15R3 5 85-305 70-430 15 340mA 1 3600VAC SIP 26.40*14.73*11.00
LS05-13B15R3-F 5 85-305 70-430 15 340mA 1 3600VAC SIP 27.84*11.60*17.60
LS05-13B24R3 5 85-305 70-430 24 210mA 1 3600VAC SIP 26.40*14.73*11.00
LS05-13B24R3-F 5 85-305 70-430 24 210mA 1 3600VAC SIP 27.84*11.60*17.60
LS10-13B03R3 6.6 85-305 100-430 3.3 2000mA 1 3600VAC SIP 32.00*17.20*15.05
LS15-13B03SS 9.9 85-305 100-430 3.3 3000mA 1 3000VAC SIP 44.50*24.00*15.00
LS15-13B03SS-F 9.9 85-305 100-430 3.3 3000mA 1 3000VAC SIP 44.50*24.00*15.00
LS10-13B05R3 10 85-305 100-430 5 2000mA 1 3600VAC SIP 32.00*17.20*15.05
LS10-13B09R3 10 85-305 100-430 9 1100mA 1 3600VAC SIP 32.00*17.20*15.05
LS10-13B12R3 10 85-305 100-430 12 830mA 1 3600VAC SIP 32.00*17.20*15.05
LS10-13B15R3 10 85-305 100-430 15 670mA 1 3600VAC SIP 32.00*17.20*15.05
LS10-13B24R3 10 85-305 100-430 24 420mA 1 3600VAC SIP 32.00*17.20*15.05
LS15-13B05SS 14 85-305 100-430 5 2800mA 1 3000VAC SIP 44.50*24.00*15.00
LS15-13B05SS-F 14 85-305 100-430 5 2800mA 1 3000VAC SIP 44.50*24.00*15.00
LS15-13B09SS 15 85-305 100-430 9 1670mA 1 3000VAC SIP 44.50*24.00*15.00
LS15-13B09SS-F 15 85-305 100-430 9 1670mA 1 3000VAC SIP 44.50*24.00*15.00
LS15-13B12SS 15 85-305 100-430 12 1250mA 1 3000VAC SIP 44.50*24.00*15.00
LS15-13B12SS-F 15 85-305 100-430 12 1250mA 1 3000VAC SIP 44.50*24.00*15.00
LS15-13B15SS 15 85-305 100-430 15 1000mA 1 3000VAC SIP 44.50*24.00*15.00
LS15-13B15SS-F 15 85-305 100-430 15 1000mA 1 3000VAC SIP 44.50*24.00*15.00
LS15-13B24SS 15 85-305 100-430 24 625mA 1 3000VAC SIP 44.50*24.00*15.00
LS15-13B24SS-F 15 85-305 100-430 24 625mA 1 3000VAC SIP 44.50*24.00*15.00
