10W ultra-small dual-outputs AC/DC converter LS10-13Dxx Series

10W ultra-small dual-outputs AC/DC converter LS10-13DXX Series.jpg

MORNSUN expands the LS series with dual-outputs in the 305RAC family in response to market demands. 5W dual-output LS05-13Dxx Series and 5W dual isolated output LS05-13Hxx Series, we introduce the new 10W dual-output LS10-13Dxx Series, which can be widely used in industrial control system, smart home, smart building, intelligent agriculture, household appliance, etc.

The 10W products keep the same advantages of this series such as ultra-small size (34.5*18*14.75mm), wide input voltage range, wide operating temperature range, and simple peripheral circuit. It complies with IEC/EN61558、IEC/EN60335、UL/IEC/EN62368 standards, with complete protection function, and with output short circuit, over-current, over-voltage protection, which can run stable and reliable and is suitable for a variety of complex working environments.

Advantages of AC DC converter LS10-13Dxx

(1) Ultra-small size (34.5*18*14.75mm).

(2) Wide input voltage range: 85-305VAC/70-430VDC.

As part of the 305RAC (Reliable under All Conditions) family, LS10-13Dxx can achieve an input voltage range of 85 VAC to 305VAC, which meets the global universal voltage requirements of 110/220/277VAC in different regions.

(3) Wide operating temperature range: -40℃ to +85℃(No derating at a low temperature)

(4) Stable output, with complete protection function

  a. Output short circuit, over-current, and over-voltage protection;

  b. The main voltage accuracy is 2%, and the load regulation is 1%;

  c. Cross regulation: < 30%

(5) Simple peripheral circuit, good EMC performance

  a. It can achieve different requirements with a simple peripheral circuit for different applications, and is suitable for indoor and poor outdoor conditions which have requirements for input voltage, temperature, altitude, and electromagnetic interference, etc.

  b. It is designed to achieve conduct radiation CLASS B with a simple peripheral circuit.

  c. It is designed to achieve EFT IEC/EN61000-4-4 ±4kV (Application circuit 1, 2, 3, 4)

  d. It is designed to achieve Surge IEC/EN61000-4-5 line to line ±1kV (Application circuit 1, 2)/ line to line ±2kV (Application circuit 3, 4)

Applications of AC DC converter LS10-13Dxx

LS10-13Dxx Series can be widely used in industrial control system, smart home, smart building, intelligent agriculture, household appliance especially suitable for the application where required small size and low cost.

The typical application of LS10-13DXX Series is Equipment of Smart home.jpg

Features of AC DC converter LS10-13Dxx

  Ultra-wide input voltage range: 85-305VAC and 70-430VDC)

  Meets the global universal voltage requirements of 110/220/277VAC) in a different region

  Wide operating temperature range: -40℃ to +85℃

  Multi-application flexible layout

  Compact size(34.5*18*14.75mm), high power density, with dual output

  3600VAC high isolation

  Output short circuit, over-current, over-voltage protection

  Comply with IEC/EN61558、IEC/EN60335、UL/IEC/EN62368 standards(EN62368 is pending)

* For detailed information please refer to the related datasheet, product news is for reference only.
Please refer to the technical manual for specific product parameters:

Series Power(W) Vin(VAC) Vin(VDC) Vout(VDC) Iout No. of Outputs Isolation Package Dimension(mm) Footprint & 3D Markings Datasheet Sample Buy
LS10-13D0505-06 10 85-305 70-430 5,5 1400mA,600mA 2 3600VAC SIP 34.50*18.00*14.75
LS10-13D1212-02 10 85-305 70-430 12,12 630mA,400mA 2 3600VAC SIP 34.50*18.00*14.75
LS10-13DY505-06 10 85-305 70-430 5.7,5 1230mA,600mA 2 3600VAC SIP 34.50*18.00*14.75
LS10-13DY512-04 10 85-305 70-430 5.7,12 910mA,400mA 2 3600VAC SIP 34.50*18.00*14.75
LS10-13DY524-02 10 85-305 70-430 5.7,24 910mA,200mA 2 3600VAC SIP 34.50*18.00*14.75
