Requirements of Converters for Smart Meters
|
|
Smart meters are big news.
With more advanced communication interfaces and more powerful microprocessors being demanded, three-phase AC/DC power supply gets critical to the design.
Wide input voltages (90-528VAC),extremely compact size, high isolation, high efficiency, multiple protection, good EMC performance, and low cost
Mornsun LS03-16BxxSS/LD03-16Bxx series may be the answer!
MORE INFO.>>
|
|
|
|
LS03-16BxxSS/LD03-16Bxx-----Designed for Three-phase Four-wire Electric Power System
|
|
- 90-528VAC input range covers requirements of 3×220VAC/380/480VAC nominal voltage
- AC and DC dual-use (input from the same terminal)
- Isolation: 4000VAC (SIP)/ 3000VAC (DIP)
- LS series: DIY type, compact size
- Operating temperature: -40℃ to +85℃
- Efficiency up to 76%
- Meet UL60950/EN60950/FCC part 15 standards
|
|
|
|
Smart Meters Application
|
|
1. LS03-16BxxSS get and convert AC input directly from any phase voltage or line voltage into isolated DC power.
2. Our matching TD501D485H integrates DC-DC isolation and RS485 to save your engineering time.
|
|
