R3 DC/DC Converter Features: No-load consumption low to 0.12W More info

R3 Products
  • 3~30 watt available
  • Input voltage range: 4:1
  • Full-load efficiency up to 90%, Light-load efficiency up to 78%
    No-load consumption low to 0.12W
  • Isolation voltage: 1500/3000/6000 VDC
  • Operating temperature: -40℃~+85℃
  • Input under-voltage, output over-voltage, short-circuit, over-current protection
  • CE/UL certified

Railway DC/DC Converter Features: Suitable for railway application More info

URB1D Series
  • 6~150 watt available
  • Input voltage range: 40-160VDC
  • Efficiency up to 92%
  • Isolation voltage: 3000VDC
  • Operating temperature: -40℃~+100℃
  • Input under-voltage, output over-voltage, over-current, short-circuit, over-temperature protection
  • International standard: 1/4 brick
  • Meet requirements of UL60950 and railway standard EN50155

Photovoltaic Power Supply Features: Input voltage range 100~1000 VDC More info

PV Series
  • 5~40 watt available
  • Ultra-wide input voltage range: 100~1000 VDC
  • Isolation voltage: 4000VAC
  • Operating temperature: -40℃~+70℃
  • Output over-voltage, short-circuit(automatic recovery), input anti-reverse voltage protection
  • No derating at -40~+70℃ & 150~1000VDC input
  • CE/UL certified

Power Supply for Sic Mosfet Driver Features: Targets SiC Mosfet drivers More info

QA01C Series
  • Capacitive load: 220μF
  • SIP package
  • Isolation voltage: 3500VAC/6000VDC
  • Operating temperature: -40℃~+105℃
  • Efficiency up to 83%
  • Ultra low-volume isolation capacitance
  • Continuous short-circuit protection
  • CE/UL certified

Without Electrolytic Capacitor AC/DC Converter Features: High performance at low temperature More info

LN Series
  • Input voltage range: 165~264VAC
  • 5 years warranty
  • Operating temperature: -40℃~+70℃
  • No detating at low temperature
  • Isolation voltage: 3000VAC
  • Compact size: 37.0x24.5x18.0mm
  • EMI meet Class B without external circuit, Level 4 surge immunity
  • Over-current, short-circuit protection
  • CE/UL certified

DIN-Rail AC/DC Converter Features: High efficiency More info

LI Series
  • Input voltage range: 85~264VAC
  • Efficiency: 92%
  • Active PFC, PFC: 0.96(Typ.)
  • Isolation voltage: 3000VAC
  • Input under-voltage, short-circuit, over-current, over-voltage, over-temperature protection
  • DIN-Rail mounting: 60*125*120mm
  • Remote ON/OFF
  • EMC: EN55022, Class B
  • CE/UL certified
